H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
Nest Association and Reproductive Microhabitat of the
Threatened Blackside Dace, Chrosomus cumberlandensis
Hayden T. Mattingly1,* and Tyler R. Black1,2
Abstract - Chrosomus cumberlandensis (Blackside Dace) is a federally protected cyprinid
fish found in small tributaries of the upper Cumberland River system in southeastern
Kentucky and northeastern Tennessee. Relatively little is known about the species’ reproductive
ecology and early life history. From a small number of field observations, the
species is known to spawn as an associate with other cyprinid nest-building hosts, namely
Campostoma anomalum (Central Stoneroller) and Semotilus atromaculatus (Creek
Chub). In the present study, we first analyzed Blackside Dace co-occurrence patterns with
other cyprinids to predict the relative importance of each species to Blackside Dace nestassociation
behavior. We next studied Blackside Dace spawning activities in seven 200-m
reaches in five Kentucky streams during May–July 2006 to document nest associations
and measure microhabitat conditions at spawning and non-spawning locations. Three of
the seven study reaches were impacted by active logging operations. We observed 25
Blackside Dace spawning events, and all 25 were associated with Creek Chub nests, consistent
with predictions from our species co-occurrence analysis. Spawning microhabitats
were located in areas with significantly greater mean wetted-channel widths, slower column
and bottom velocities, lower silt levels, lower substrate embeddedness, and larger
subdominant substrate particles compared to non-spawning microhabitats. Study reaches
with adjacent active logging had significantly greater mean silt levels, substrate embeddedness,
water temperature, and conductivity values compared to reaches with no active
logging, although 4 of the 25 spawning events occurred in reaches with active logging.
Our results highlight the importance of cyprinid nest-building hosts (especially Creek
Chub) to Blackside Dace reproductive ecology, and they also reinforce the need to maintain
the integrity of Blackside Dace streams at the whole-commu nity level.
Introduction
Strategies for conserving biodiversity are best developed with knowledge
of important life-history and ecological characteristics of imperiled species.
However, the reproductive ecology of many imperiled aquatic species remains
unknown or only partially studied for a variety of reasons. An illustration of this
pattern is provided by the species-rich minnow family, Cyprinidae, in which
spawning modes are known for only 13 of 46 imperiled species (Johnston 1999).
Johnston and Page (1992) reviewed the reproductive strategies of minnows
and classified the strategies into eight categories. The most primitive and common
behavior is the broadcasting of gametes with no preparation of the substrate.
Another strategy with no substrate preparation is termed crevice spawning. The
other six strategies involve some preparation or use of substrate to form a nest in
1Department of Biology, Box 5063, Tennessee Technological University, Cookeville,
TN 38505. 2Current Address - North Carolina Wildlife Resources Commission, 1718
NC Hwy 56 W, Creedmoor, NC 27522. *Corresponding author - hmattingly@tntech.edu.
Ecology and Conservation of the Threatened Blackside Dace, Chrosomus cumberlandensis
2013 Southeastern Naturalist 12(Special Issue 4):49–63
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
50
Vol. 12, Special Issue 4
which eggs are deposited and fertilized. Parental care in the form of nest guarding
is provided by males in some instances.
One of the fascinating and complex facets of cyprinid reproduction is the nestassociation
behavior displayed by certain species. Nest association occurs when
one species, the host, prepares a nest that another species, the associate, uses for
spawning (Johnston and Page 1992). The host species is typically another cyprinid,
but some associates are known to use centrarchid nests (e.g., Fletcher 1993,
Johnston and Page 1992). More than one associate species may spawn in a host’s
nest. For example, Cashner and Bart (2010) found eggs of two associate species
along with host eggs in the nest of Nocomis leptocephalus (Girard) (Bluehead
Chub), and Johnston and Page (1992) observed as many as six associate species
at one time over Nocomis nests. Nest-association behavior has been reported for
at least 33 cyprinid species (Johnston and Page 1992).
Some cyprinids show flexibility in their reproductive behavior by spawning
either as an associate in the nests of hosts or independent of the host by broadcasting
or by building their own nests (Johnston and Page 1992). Understanding the
degree of host dependence and host specificity exhibited by a particular species is
important. For example, if an imperiled broadcasting species is obligated to only
spawn in nests of one or more host species, then conservation of the associate is
intimately tied to conservation of the hosts, a situation paralleling that of freshwater
mussels. Johnston (1999) has emphasized the importance of understanding
cyprinid reproductive strategies to better inform conservation efforts.
Chrosomus cumberlandensis (Starnes and Starnes) (Blackside Dace) is a
threatened cyprinid species endemic to the upper Cumberland River system
in Kentucky and Tennessee (Eisenhour and Strange 1998, Starnes and Starnes
1978). Blackside Dace reproductive behavior was first reported by Starnes and
Starnes (1981) who confirmed the species used a broadcasting spawning mode
over the nest of Campostoma anomalum (Rafinesque) (Central Stoneroller). Cicerello
and Laudermilk (1996) later observed a school of nuptial Blackside Dace
over the nest of Semotilus atromaculatus (Mitchill) (Creek Chub), although actual
spawning was not observed. To date, no field observations of Blackside Dace
spawning independent of nest-building cyprinids have been reported, although
most authors have presumed that independent spawning may occur .
Cicerello and Laudermilk (1996) offered three findings regarding Blackside
Dace nest association that needed confirmation by additional research.
First, their observations suggested that Blackside Dace spawn in Creek Chub
nests, even in relatively silt-free streams. Second, they predicted that Creek
Chub was a more important host than either of the two upper Cumberland River
stoneroller species (Central Stoneroller and Campostoma oligolepis Hubbs and
Greene [Largescale Stoneroller]) because Blackside Dace co-occurred more
often with Creek Chub than stonerollers in their collections. Third, they opined
that cyprinid hosts play a vital role in Blackside Dace conservation by providing
spawning habitat both in streams with relatively clean substrates, as well as
streams degraded by siltation.
51
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
Conservation efforts for Blackside Dace would be enhanced by a more comprehensive
understanding of its reproductive behavior. Our objectives in the
present study were to (1) analyze patterns of Blackside Dace co-occurrence with
other cyprinid species to allow predictions of the relative importance of cyprinid
hosts, (2) observe Blackside Dace spawning events in the field under varied conditions
of substrate cleanliness to determine host species and possibly document
independent spawning, and (3) measure microhabitat conditions at spawning
and non-spawning locations to characterize the range of conditions under which
Blackside Dace reproduction occurs in the field.
Our approach to addressing these objectives entailed two phases. We first used
two fish-collection datasets from the upper Cumberland River system to analyze
Blackside Dace co-occurrence patterns with selected cyprinid species. We next
conducted a field study of Blackside Dace reproductive activities at seven sites
located in five streams in southeastern Kentucky. Two of the study streams had
active logging operations during our field work, and substrates in these streams
were subjected to elevated levels of siltation. The other three streams had no
active logging operations adjacent to or upstream of our study sites, thereby providing
less-silted substrate conditions for observation of spaw ning activities.
Methods
Species co-occurrence patterns
We used two upper Cumberland River fish-collection datasets to analyze
patterns of cyprinid species co-occurrence. The first dataset was provided by
Laudermilk and Cicerello (1998) who reported 450 collections from Kentucky
during 1982–1994, with most being made during 1993–1994. The second dataset
was provided by Black et al. (2013 [this issue]) who sampled 119 sites
in Kentucky and Tennessee during 2003–2006. For each set of data, collection
records were selected if at least one of the following cyprinid species was present:
Central Stoneroller, Largescale Stoneroller, Blackside Dace, Chrosomus
erythrogaster (Rafinesque) (Southern Redbelly Dace), Luxilus chrysocephalus
Rafinesque (Striped Shiner), Nocomis micropogon (Cope) (River Chub),
Rhinichthys obtusus Agassiz (Western Blacknose Dace), and Creek Chub.
The two stoneroller species were combined for analyses because of their ecological
similarity and lack of spatial overlap (Central Stoneroller occurs above
Cumberland Falls, and Largescale Stoneroller occurs below the falls; Burr and
Warren 1986). Three hundred and ninety-five of 450 collection records by Laudermilk
and Cicerello (1998) and 119 of 119 records by Black et al. (2013 [this
issue]) noted the occurrence of at least one of these cyprinid species.
All of the cyprinids listed above could potentially have strong ecological
interactions with Blackside Dace during reproductive activities. Blackside
Dace, Southern Redbelly Dace, and Western Blacknose Dace are broadcasting
spawners that do not prepare their own nest during spawning. However,
all three species at least occasionally interact with nest-building cyprinids by
spawning in prepared nests of the hosts. Southern Redbelly Dace are known to
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
52
Vol. 12, Special Issue 4
use Campostoma, Luxilus, and Nocomis nests and Western Blacknose Dace are
known to use Nocomis nests (Etnier and Starnes 1993, Johnston and Page 1992).
However, Blackside Dace spawning activities have only been observed over
Central Stoneroller and Creek Chub nests, and it remains unknown whether it
can spawn independent of a host species (Cicerello and Laudermilk 1996, Starnes
and Starnes 1981).
Central Stoneroller, Largescale Stoneroller, Striped Shiner, River Chub, and
Creek Chub are nest-building species that could potentially serve as hosts to the
three aforementioned broadcasting dace species. The stonerollers and Striped
Shiner are pit-building species that provide no parental care subsequent to egg
deposition, Creek Chub is a pit-ridge-building species in which males cover eggs
with gravel substrate after egg deposition, and River Chub is a mound-building
species in which males also cover eggs with gravel (Boschung and Mayden 2004,
Etnier and Starnes 1993, Johnston 1999). Creek Chub and River Chub males
therefore provide rudimentary parental care with their nest-maintenance and eggcovering
activities.
We used two metrics, constancy and fidelity, to express co-occurrence patterns
of the selected cyprinid species, considering each dataset separately. For any
given species, constancy was the number of occurrences with Blackside Dace as
a percentage of total Blackside Dace occurrences. Fidelity was the number of occurrences
with Blackside Dace as a percentage of total occurrences of the given
species. Pflieger (1978) originally defined constancy, dominance, and fidelity in
his study of fish species co-occurrence patterns with Etheostoma nianguae Gilbert
and Meek (Niangua Darter) in Missouri, and Wagner et al. (2010) recently
used these metrics in their distributional analysis of Orconectes williamsi Fitzpatrick
(Williams’ Crayfish) in Arkansas. Although other co-occurrence metrics
are available in the literature (e.g., Peres-Neto 2004), constancy and fidelity were
ideally suited for our study to identify patterns that could indicate strong species
interactions during Blackside Dace reproductive activities. Different ecological
and evolutionary processes certainly could influence the observed co-occurrence
patterns, but we interpreted high constancy of a species with Blackside Dace as
a necessary prerequisite for a strong nest-association relation ship.
Field study of Blackside Dace spawning activities
Study sites. We selected seven 200-m stream reaches in which to observe
Blackside Dace spawning activities. The reaches were located in 5 different
streams occupied by Blackside Dace in Knox, McCreary, and Pulaski counties
in southeastern Kentucky (Fig. 1, Table 1). We identified reaches with a variety
of Blackside Dace background densities, and with presumably different levels
of siltation on the substrate. Black et al. (2013 [this issue]) determined density
of Blackside Dace at 6 of the 7 reaches in 2003 and 2005, and densities ranged
from 0.0–49.8 dace per 100 m2 (Table 1). We selected active logging as a land-use
disturbance that was likely to introduce fine sediments to the stream, and thereby
create conditions that might discourage independent spawning by Blackside
53
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
Dace, and encourage reliance on a nest-building host species to provide clean
substrate for spawning. In 3 reaches located in 2 streams, we observed active
logging operations adjacent to or upstream from the study reaches (Table 1). We
Figure 1. Map of the study area in southeastern Kentucky. Triangles indicate 200-m study
reaches with active logging and circles indicate study reaches without active logging. See
Table 1 and text for additional details about the study reaches.
Table 1. Characteristics of 200-m stream reaches in southeastern Kentucky where Chrosomus
cumberlandensis (Blackside Dace) spawning activities were monitored weekly from 4 May–7 July
2006. Stream reach numbers refer to relative downstream (1) and upstream (4) locations within
streams, and are consistent with Black et al. (2013 [this issue]). Blackside Dace background densities
were determined for 6 of the sites in 2003 or 2005 by Blac k et al. (2013 [this issue]).
Blackside Dace
Blackside Dace
background density
spawning surveys in 2006
Spawning
Dace per Year Sampling events Active
Stream reach County 100 m2 measured dates observed logging?
Big Lick Branch 3 Pulaski 49.8 2003 4 May–29 June 14 No
Big Lick Branch 4 Pulaski - - 5 May–30 June 6 No
Grubb Branch 1 Knox 23.2 2005 12 May–5 July 0 No
Rock Creek 4 McCreary 44.4 2003 4 May–6 July 1 No
Roaring Fork 1 Knox 10.2 2005 13 May–7 July 2 Yes
Roaring Fork 2 Knox 0.0 2005 10 May–7 July 0 Yes
Right Branch Moore Creek 1 Knox 9.3 2005 13 May–6 July 2 Yes
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
54
Vol. 12, Special Issue 4
did not measure the spatial extent of the logging activities, nor did we otherwise
attempt to quantify the amount of logging disturbance. In contrast, in the remaining
four reaches (Table 1), we observed no active or recent logging operations
adjacent to or upstream from the reach.
Spawning activities. A two-person crew performed weekly surveys from 4
May–7 July 2006 to observe Blackside Dace spawning activities. Each person
walked slowly upstream through the reach, on or near opposite stream banks
when possible. Spawning activities were observed from the nearest bank or the
bank with greatest visibility; binoculars were used if greater resolution was warranted.
If a school of nuptial individuals was spotted, we observed its behavior
and/or spawning activities for 20 min.
We used three categories to classify Blackside Dace reproductive activities:
(1) schooling nuptial individuals, (2) males corralling females to spawning area,
and (3) males pressing female to substrate and vibrating in unison (clasping). We
defined a “spawning event” as either category (2) or (3), because it was unclear
when gametes were actually released, and because both corralling and clasping
indicated that appropriate spawning habitat had been selected. If a spawning
event was observed, we marked the location with survey flagging to allow later
measurements of microhabitat conditions at the spawning site. When spawning
events occurred over a host nest, we visually identified the host-species, if present,
and assessed its nest. Our criteria for comparing nests of taxa currently known
or suspected to host Blackside Dace spawning were as follows: the stoneroller
species excavate shallow pits with dislodged pebbles lining the periphery of the
nest, and Creek Chubs excavate a nest that contains a pit and ridge (Boschung
and Mayden 2004). Survey observations were continued until the 200-m marker
was reached, after which surveyors returned to the lower margin of the reach to
begin assessing habitat variables.
Spawning habitat measurements. If Blackside Dace spawning events were
observed during a survey, we returned to the flagging markers and measured
habitat conditions at the spawning site. The center of the spawning site itself was
evaluated as a microhabitat with a 10-cm radius, hereafter termed a spawning
microhabitat. We measured 13 habitat variables at each spawning microhabitat,
including wetted-channel width, canopy cover, silt depth, embeddedness, substrate
composition, temperature (oC), dissolved oxygen (mg/L), conductivity
(μS), water depth (cm), water velocity (cm/s) at the substrate and in the water
column, and turbidity (NTU). Wetted-channel width was measured (nearest 0.1
m) by stretching a meter tape perpendicular to stream-flow across the spawning
microhabitat. Canopy cover was visually categorized considering the entire
wetted-channel width crossing the spawning microhabitat (0 = no canopy cover,
1 = 1–25% cover, 2 = 26–50%, 3 = 51–75%, and 4 = 76–100%).
Visual estimates of silt depth, substrate embeddedness, and substrate composition
were made across the entire area of each 10-cm-radius microhabitat. Visual
estimates were checked with a ruler at the beginning of the field season. Silt depth
was the most commonly occurring depth of silt covering the protruding portion
55
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
of the substrate and was scored with a silt index (0 = 0 mm silt, 1 = 0.1–1.0 mm
silt, 2 = 1.1–2.0 mm, 3 = 2.1–3.0 mm, and 4 = >3 mm) similar to that used by
Mattingly and Galat (2002). Substrate embeddedness was categorized as the
percentage of gravel, pebble, cobble, and boulder particle surfaces covered by
fine sediment (fine sediment includes material <2 mm in diameter [sand, silt,
and clay]) as follows: 0 = “negligible” = <5% coverage with fines, 1 = “low” =
5–25%, 2 = “moderate” = 25–50%, 3 = “high” = 50–75%, and 4 = “very high”
= >75% (Bain 1999, Platts et al. 1983). Dominant and subdominant substrate
compositions were scored using a modification of the Wentworth scale: 0 = fines
<0.059 mm, 1 = sand 0.06–1.0 mm, 2 = gravel 2–15 mm, 3 = pebble 16–63 mm,
4 = cobble 64–256 mm, 5 = boulder >256 mm, and 6 = bedrock (Bain 1999).
Water depth was measured with a top-setting wading rod. Water velocity in
the water column above the microhabitat was measured with a Marsh-McBirney
Flo-Mate 2000 portable flowmeter, with the probe located at six-tenths depth
as measured down from the water surface or four-tenths depth as measured up
from the streambed (Gordon et al. 1992). Water velocity was also measured at
the streambed with the probe at its lowest possible setting (i.e., bottom velocity).
Temperature, dissolved oxygen, and conductivity were measured with a Yellow
Springs Instrument (YSI) Model 85 meter, and turbidity was measured with an
HF Scientific MicroTPI.
All microhabitat parameters were measured once at each spawning microhabitat
except turbidity, water depth, and water velocities. Turbidity was measured
above the center of the spawning microhabitat when one such site occurred, but
when multiple sites occurred in close proximity (<1 m apart), only one sample
was taken between spawning areas. Water depths and velocities were determined
by averaging four values immediately surrounding each spawning microhabitat
(i.e., upstream, downstream, right, and left) to avoid damaging eggs or embryos
that might have been present in the center of the microhabitat.
Non-spawning habitat measurements. Non-spawning microhabitats were
established by delineating transect points as follows. Like the spawning microhabitats,
each non-spawning microhabitat was considered to be a circle on
the streambed with a 10-cm radius. We partitioned the 200-m study reaches
using transects perpendicular to stream-flow at 10-m intervals, for a total of
21 transects per reach. We sampled 5 or 6 of the 21 transects each week. Specifically,
we sampled transects 1, 5, 9, 13, 17, and 21 on the first week; transects
2, 6, 10, 14, and 18 on the second week; transects 3, 7, 11, 15, and 19 on
the third week; and transects 4, 8, 12, 16, and 20 on the fourth week. On the
fifth week we resampled transects 1, 5, 9, 13, 17, and 21, but sampling took
place approximately 1.0 m upstream from where we sampled the first week.
Throughout the 9-week study period, we continued this pattern of systematically
rotating through transects on a 4-week interval, moving upstream 1 m
each time a given transect was revisited.
The number of microhabitat points sampled per transect was determined by
the wetted-channel width, with one point sampled for every meter of width.
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
56
Vol. 12, Special Issue 4
Within each meter, the precise location of a transect point was determined by
drawing a number between 1 and 9. Each number represented a possible point at
10-cm increments (e.g., the number 3 represented a transect poi nt at 30 cm).
All non-spawning microhabitat measurements were taken at the transect-point
as described above for the spawning microhabitats, with the following exceptions.
Instead of averaging four values for water depth and velocity readings,
we simply measured these variables once in the center of the microhabitat. Also,
turbidity values were taken at the upper and lower periphery of each reach during
surveys and then averaged to obtain one turbidity value for the reach. Each
non-spawning microhabitat within the reach was then assigned the same turbidity
value for that sampling date.
Statistical analyses. For each habitat variable, we calculated a mean value
separately for spawning and non-spawning microhabitats in each of the seven
study reaches. Next we used a series of nonparametric, Kruskal-Wallis twosample
tests to address the following questions: (1) did conditions differ
between spawning (n = 5 reaches) and non-spawning (n = 7 reaches) microhabitat
mean values for any habitat variable; and (2) did non-spawning microhabitat
mean values differ between reaches with (n = 3) and without (n = 4) active
logging for any habitat variable? Tests were conducted using the NPAR1WAY
procedure in SAS Version 9.2 (http://www.sas.com/software/sas9/). Statistical
significance was evaluated with α = 0.05.
Results
Species co-occurrence patterns
Blackside Dace were observed in 95 collections during 1982–1994 and 78
collections during 2003–2006. Species constancy with Blackside Dace was
highest for Creek Chub, exceeding 90% in both datasets, and easily surpassing
constancy values for other species (Table 2). The only other species with constancy
>50% were the stonerollers at 56.4% in the 2003–2006 collections. Most
other species had constancy values of 20–35%, although River Chub never occurred
with Blackside Dace. Fidelity values with Blackside Dace were highest
for Southern Redbelly Dace in each dataset, at 43.3% for 1982–1994 and 90.3%
for 2003–2006 (Table 2).
Field study of Blackside Dace spawning activities
Spawning activities. Creek Chubs were actively constructing nests during
the first week of May, although nuptial coloration and schooling behaviors by
Blackside Dace were not observed until mid-May. Twenty-five Blackside Dace
spawning events (20 corralling and 5 clasping) were observed 12 May–12 June
2006, when water temperatures for such events ranged from 11.9–18.2 oC (mean
± SD = 15.3 ± 2.1 oC). Sixteen events were observed in May and nine were seen
in June, with spawning activity ceasing after 12 June, and Creek Chub nest maintenance
ending the following week.
57
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
All 25 Blackside Dace spawning events occurred over Creek Chub nests,
and no observations of independent spawning were noted. Blackside Dace
spawned in Creek Chub nests in Big Lick Branch, Rock Creek, Roaring Fork,
and Right Branch Moore Creek, even in the presence of active logging disturbances
(Table 1). However, most events were observed in Big Lick Branch, a
stream with relatively high densities of Blackside Dace and with no active logging
in its watershed. Schools of nuptial males were only observed over Creek
Chub nests and ranged from 3 to ≈60 individuals. Corralling and clasping behaviors
were exhibited by 2–4 males pursuing one female. In addition, most
individuals in the school probed the nest after a clasping event, presumably
feeding on released eggs.
Differences between spawning and non-spawning microhabitats. Spawning
microhabitats were located in areas with significantly greater mean wettedchannel
widths, slower column and bottom velocities, lower silt levels, lower
substrate embeddedness, and larger subdominant substrate particles compared to
the non-spawning, transect-point microhabitats (Kruskal-Wallis χ2 ≥ 5.129; P ≤
0.0235; Table 3). Notably, all 25 spawning microhabitats had only negligible levels
of substrate embeddedness and no measurable levels of silt covering substrate
particles, both presumably due to the nest-building and -maintenance activities
Table 2. Patterns of species co-occurrence with Chrosomus cumberlandensis (Blackside Dace) for
selected cyprinid species in the upper Cumberland River drainage. Two sets of data were evaluated:
one from 1982–1994 collections in Kentucky (n = 395; Laudermilk and Cicerello 1998) and
another from 2003–2006 collections in Kentucky and Tennessee (n = 119; Black et al. 2013 [this
issue]) in which at least one of the selected species was collected. BSD = Blackside Dace. Constancy
(C) = number of occurrences with Blackside Dace as a percentage of total Blackside Dace
occurrences. Fidelity (F) = number of occurrences with Blackside Dace as a percentage of total
occurrences of the species.
Occurrences
Species Total With BSD C (%) F (%)
1982–1994 collections
Campostoma spp. (Central Stoneroller; Largescale Stoneroller) 164 28 29.5 17.1
Chrosomus cumberlandensis (Blackside Dace) 95 - - -
Chrosomus erythrogaster (Southern Redbelly Dace) 60 26 27.4 43.3
Luxilus chrysocephalus (Striped Shiner) 68 3 3.2 4.4
Nocomis micropogon (River Chub) 12 0 0.0 0.0
Rhinichthys obtusus (Western Blacknose Dace) 85 20 21.1 23.5
Semotilus atromaculatus (Creek Chub) 331 87 91.6 26.3
2003–2006 collections
Campostoma spp. (Central Stoneroller; Largescale Stoneroller) 65 44 56.4 67.7
Chrosomus cumberlandensis (Blackside Dace) 78 - - -
Chrosomus erythrogaster (Southern Redbelly Dace) 31 28 35.9 90.3
Luxilus chrysocephalus (Striped Shiner) 26 18 23.1 69.2
Nocomis micropogon (River Chub) 0 0 0.0 0.0
Rhinichthys obtusus (Western Blacknose Dace) 40 22 28.2 55.0
Semotilus atromaculatus (Creek Chub) 116 75 96.2 64.7
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
58
Vol. 12, Special Issue 4
Table 3. Kruskal-Wallis two-sample tests to determine if reach mean values for habitat variables differed between spawning and non-spawning microhabitats
in Blackside Dace streams. Values for conductivity and turbidity were rounded to nearest wh ole numbers immediately before inclusion in the table.
Kruskal-Wallis
Reach mean values tests
Habitat variable Spawning microhabitats Non-spawning microhabitats χ2 P
Wetted-channel width (m) 3.1, 3.1, 3.3, 3.6, 3.8 1.8, 1.9, 2.0, 2.1, 2.3, 2.4, 2.5 8.07 0.005
Canopy cover index 3.5, 3.5, 3.9, 4.0, 4.0 3.2, 3.3, 3.6, 3.7, 3.7, 3.8, 3.8 1.49 0.222
Silt index 0, 0, 0, 0, 0 1.0, 1.0, 1.2, 1.4, 1.6, 1.7, 2.3 8.68 0.003
Embeddedness index 0, 0, 0, 0, 0 0.6, 0.7, 0.9, 1.0, 1.6, 1.9, 2.4 8.68 0.003
Dominant substrate index 3.0, 3.0, 3.3, 3.5, 3.6 2.6, 2.9, 3.4, 3.4, 3.5, 3.5, 3.6 0.06 0.807
Subdominant substrate index 2.4, 2.5, 3.0, 4.0, 4.0 2.1, 2.2, 2.2, 2.3, 2.3, 2.4, 2.7 5.60 0.018
Temperature (°C) 14.0, 14.4, 15.0, 15.7, 17.9 15.1, 16.0, 16.5, 16.6, 16.9, 17.0, 17.1 2.38 0.123
Dissolved oxygen (mg/L) 7.9, 8.3, 8.3, 8.6, 9.1 8.1, 8.4, 8.4, 8.5, 8.5, 8.6, 8.7 0.17 0.684
Conductivity (μS) 23, 29, 47, 90, 181 23, 29, 54, 71, 74, 100, 182 0.24 0.626
Water depth (cm) 5, 8, 13, 23, 34 7, 9, 9, 9, 10, 11, 11 0.53 0.461
Bottom velocity (cm/s) 2, 2, 3, 4, 5 5, 5, 5, 5, 6, 7, 8 6.84 0.009
Column velocity (cm/s) 3, 3, 3, 5, 5 4, 5, 5, 6, 6, 6, 9 5.13 0.024
Turbidity (NTU) 1, 2, 6, 8, 11 1, 2, 7, 9, 10, 15, 21 0.66 0.416
59
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
of Creek Chub males. Mean wetted-channel widths in spawning locations were
3–4 m, consistently wider than average values for transects in non-spawning locations
(Table 3).
Differences between microhabitats in reaches with and without logging. Study
reaches with active logging had significantly greater mean silt levels, substrate
embeddedness, water temperature, and conductivity values compared to reaches
with no active logging (Kruskal-Wallis χ2 = 4.50; P = 0.0339; Table 4). Despite
these trends, 4 of the 25 spawning events were observed in Creek Chub nests in
two reaches with active logging (Table 1).
Discussion
Blackside Dace spawning events were observed over a 32-day timespan (12
May–12 June 2006) during our study. Across its distributional range, however,
the spring spawning season for Blackside Dace may begin earlier and extend later
than these dates. As with many fishes, the exact timing of spawning is probably
driven by a combination of temperature and photoperiod, and therefore spatial
and temporal variation should be expected. The single Blackside Dace spawning
event reported by Starnes and Starnes (1981) occurred on 17 May 1981 at a
water temperature of 17.5 oC, which is within the range of dates and temperatures
observed in our study. However, based on the presence of mature ova in females,
Starnes and Starnes (1981) suggested that spawning most likely begins in April
and extends through June. In addition, the timing of Blackside Dace spawning
also appears dependent on the timing of host-species nesting, as indicated by the
results of our current study.
Table 4. Kruskal-Wallis two-sample tests to determine if reach mean values for non-spawning,
transect-point microhabitats in Blackside Dace streams differed between reaches with and without
active logging. Values for conductivity and turbidity were rounded to nearest whole numbers immediately
before inclusion in the table.
Reach mean values for
non-spawning microhabitats Kruskal-Wallis
Reaches with Reaches with tests
Habitat variable active logging no active logging χ2 P
Wetted-channel width (m) 1.9, 2.0, 2.4 1.8, 2.1, 2.3, 2.5 0.13 0.724
Canopy cover index 3.2, 3.7, 3.8 3.3, 3.6, 3.7, 3.8 0.13 0.724
Silt index 1.6, 1.7, 2.3 1.0, 1.0, 1.2, 1.4 4.50 0.034
Embeddedness index 1.6, 1.9, 2.4 0.6, 0.7, 0.9, 1.0 4.50 0.034
Dominant substrate index 2.9, 2.6, 3.5 3.4, 3.4, 3.5, 3.6 2.04 0.154
Subdominant substrate index 2.2, 2.2, 2.4 2.1, 2.3, 2.3, 2.7 0.13 0.724
Temperature (°C) 16.9, 17.0, 17.1 15.1, 16.0, 16.5, 16.6 4.50 0.034
Dissolved oxygen (mg/L) 8.1, 8.4, 8.5 8.4, 8.5, 8.6, 8.7 2.00 0.157
Conductivity (μS) 74, 100, 182 23, 29, 54, 71 4.50 0.034
Water depth (cm) 7, 9, 10 9, 9, 11, 11 1.24 0.266
Bottom velocity (cm/s) 5, 7, 8 5, 5, 5, 6 1.86 0.172
Column velocity (cm/s) 6, 6, 9 4, 5, 5, 6 3.43 0.064
Turbidity (NTU) 7, 15, 21 1, 2, 9, 10 2.00 0.157
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
60
Vol. 12, Special Issue 4
The relative importance of Creek Chub to Blackside Dace reproductive success
seems to be much greater than that of other co-occurring cyprinid species (Fig. 2).
Our constancy pattern analysis identified Creek Chub as a potentially important
species, but such high constancy could have been a simple function of the cosmopolitan
distribution of Creek Chub in the study area (Burr and Warren 1986,
Laudermilk and Cicerello 1998). It was only after our field study that we gained
greater confidence in the importance of Creek Chub to Blackside Dace reproductive
ecology. All 25 observed spawning events occurred in Creek Chub nests,
regardless of the presence or absence of logging disturbance at the study sites.
The stream with the lowest embeddedness and silt levels in our study, Big
Lick Branch, hypothetically provided the most suitable conditions under which
independent spawning could occur, given the microhabitat conditions measured
in that stream. However, all 20 observed spawning events in Big Lick Branch occurred
in Creek Chub nests. During minnow trapping events, Detar and Mattingly
(2013 [this issue]) collected a number Blackside Dace x Creek Chub hybrids (see
Eisenhour and Piller 1997) in Big Lick Branch, a relatively undisturbed stream
system, suggesting that rates of hybridization are probably related to multiple
factors. Rakes et al. (1999, 2013 [this issue]) describe the re sponse of Blackside
Dace in captivity to milt from other fish species. Heterospecific gamete-release
cues appear to represent a strong mechanism for induction of reproductive activities
by Blackside Dace. However, Rakes et al. (2013 [this issue]) recently found
that Blackside Dace can spawn independently in captivity, as discovered during
April—May 2013, without the presence of (or cues from) other fishes, representing
the first time that independent spawning has been reported for Blackside
Dace. Despite an ability to spawn independently in captivity, it remains unknown
whether independent spawning is practiced in a field setting.
Figure 2. Chrosomus cumberlandensis (Blackside Dace) adults in nuptial coloration
swimming near a nesting male Semotilus atromaculatus (Creek Chub), photographed on
10 June 2005 by Tyler R. Black at Grubb Branch, eastern Knox County , KY.
61
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
Microhabitat conditions measured at Blackside Dace spawning sites were
fairly narrow for certain variables (e.g., zero silt depth index, zero embeddedness
index, 100% in Creek Chub nests, channel widths 3–4 m), and the reliance
on Creek Chub nests apparently constrains Blackside Dace reproduction to microhabitats
selected by Creek Chub. Blackside Dace spawning was possible in
sites with generally elevated siltation and embeddedness, such as found in Roaring
Fork and Right Branch Moore Creek. The nest-building and -maintenance
activities of Creek Chub males apparently created isolated small microhabitat
“islands” in which spawning conditions were suitable for Blackside Dace. In
short, conservation of Blackside Dace now seems more intimately tied to conservation
of host species, such that dace populations may reproduce in streams
where conditions are somewhat degraded.
Our study did not identify a threshold of siltation or embeddedness that
entirely prevented Blackside Dace reproduction. Furthermore, we also did not
examine lethal or sub-lethal effects of siltation on embryos or other early life
history stages. Even when reproduction occurs in silted streams, we remain unsure
how well embryos, larvae, and juveniles feed, grow, and survive under such
conditions (e.g., Kemp et al. 2011; Sutherland 2007; Sutherland and Meyer 2007;
Sutherland et al. 2008; Wood and Armitage 1997, 1999). Early life stages could
be more sensitive than adults to suspended particles.
In conclusion, our study represents the first quantitative description of microhabitat
conditions at Blackside Dace spawning locations in multiple streams.
We also documented distinct differences in microhabitat conditions for several
variables between spawning locations and non-spawning transect points. Further,
we documented a strong nest-association pattern with Creek Chub, confirming
the earlier predictions of Cicerello and Laudermilk (1996). Stoneroller species
appear to be of less importance than Creek Chub to Blackside Dace reproductive
activities. The potentially obligatory relationship that Blackside Dace have with
nest-building cyprinids, especially Creek Chub, reinforces the importance of
maintaining the integrity of the whole stream community. Finally, we documented
differences in habitat conditions between stream reaches with and without
logging disturbances, and observed that Blackside Dace can spawn in both situations,
most likely due to the nest-cleaning actions of male Creek Chub. However,
we observed fewer Blackside Dace spawning events in sites with active logging,
and it remains unknown how early life stages would fare in areas with increased
silt, embeddedness, temperature, and conductivity.
Acknowledgments
We thank the US Fish and Wildlife Service, Tennessee Wildlife Resources Agency,
The Nature Conservancy, and the Department of Biology and Center for the Management,
Utilization and Protection of Water Resources at Tennessee Technological University
(TTU) for financial and other support. We appreciate the cooperation of US Department
of Agriculture Forest Service and several private landowners who granted access to their
properties. C.J. Sutherland constructed Figure 1, J.R. Darden assisted with field work,
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist
62
Vol. 12, Special Issue 4
and C. Peterson provided editorial support. Completion of the manuscript was facilitated
by a TTU Faculty Non-Instructional Assignment during 2011–2012. We especially thank
Y. Kanno for guidance and suggestions during the study. The manuscript was improved
by comments from two anonymous reviewers and the guest editor .
Literature Cited
Bain, M.B. 1999. Substrate. Pp. 95–104, In M.B. Bain and N.J. Stevenson (Eds.). Aquatic
Habitat Assessment: Common Methods. American Fisheries Society, Bethesda,
MD. 216 pp.
Black, T.R., J.E. Detar, and H.T. Mattingly. 2013. Population densities of the threatened
Blackside Dace, Chrosomus cumberlandensis, in Kentucky and Tennessee. Southeastern
Naturalist 12(Special Issue 4):6–26.
Boschung, H., Jr., and R.L. Mayden. 2004. Fishes of Alabama. Smithsonian Institution,
Washington, DC. 736 pp.
Burr, B.M., and M.L. Warren, Jr. 1986. A Distributional Atlas of Kentucky Fishes. Kentucky
State Nature Preserves Scientific and Technical Series Number 4, Frankfort,
KY. 398 pp.
Cashner, M.F., and H.L. Bart, Jr. 2010. Reproductive ecology of nest associates: Use of
RFLPs to identify cyprinid eggs. Copeia 2010:554–557.
Cicerello, R.R., and E.L. Laudermilk. 1996. Nesting association of the cyprinid fishes
Phoxinus cumberlandensis and Semotilus atromaculatus (Cyprinidae). Transactions
of the Kentucky Academy of Science 57:47.
Detar, J.E., and H.T. Mattingly. 2013. Movement patterns of the threatened Blackside
Dace, Chrosomus cumberlandensis, in two southeastern Kentucky watersheds. Southeastern
Naturalist 12(Special Issue 4):64–81.
Eisenhour, D.J., and K.R. Piller. 1997. Two intergeneric hybrids involving Semotilus
atromaculatus and the genus Phoxinus with analysis of additional Semotilus atromaculatus-
Phoxinus hybrids. Copeia 1997:204–209.
Eisenhour, D.J., and R.M. Strange. 1998. Threatened fishes of the world: Phoxinus
cumberlandensis Starnes and Starnes, 1978 (Cyprinidae). Environmental Biology of
Fishes 51:140.
Etnier, D.A., and W.C. Starnes. 1993. The Fishes of Tennessee. The University of Tennessee
Press, Knoxville, TN. 681 pp.
Fletcher, D.E. 1993. Nest association of Dusky Shiners (Notropis cummingsae) and
Redbreast Sunfish (Lepomis auritus), a potentially parasitic relationship. Copeia
1993:159–167.
Gordon, N.D., T.A. McMahon, and B.L. Finlayson. 1992. Stream Hydrology: An Introduction
for Ecologists. John Wiley and Sons, New York, NY. 526 pp.
Johnston, C.E. 1999. The relationship of spawning mode to conservation of North American
minnows (Cyprinidae). Environmental Biology of Fishes 55:21 –30.
Johnston, C.E., and L.M. Page. 1992. The evolution of complex reproductive strategies
in North American minnows (Cyprinidae). Pp. 600–621 In R.L. Mayden (Ed.).
Systematics, Historical Ecology, and North American Freshwater Fishes. Stanford
University Press, Stanford, CA. 969 pp.
Kemp, P., D. Sear, A. Collins, P. Naden, and I. Jones. 2011. The impacts of fine sediment
on riverine fish. Hydrological Processes 25:1800–1821.
Laudermilk, E.L., and R.R. Cicerello. 1998. Upper Cumberland River Drainage, Kentucky,
Fish Collection Catalog (1982–1994). Kentucky State Nature Preserves Commission,
Frankfort, KY. 469 pp.
63
H.T. Mattingly and T.R. Black
2013 Southeastern Naturalist Vol. 12, Special Issue 4
Mattingly, H.T., and D.L. Galat. 2002. Distributional patterns of the threatened Niangua
Darter, Etheostoma nianguae, at three spatial scales, with implications for species
conservation. Copeia 2002:573–585.
Peres-Neto, P.R. 2004. Patterns in the co-occurrence of fish species in streams: The role
of site suitability, morphology, and phylogeny versus species interactions. Oecologia
140:352–360.
Pflieger, W.L. 1978. Distribution, status, and life history of the Niangua Darter, Etheostoma
nianguae. Missouri Department of Conservation Aquatic Series Number 16,
Jefferson City, MO. 24 pp.
Platts, W.S., W.F. Megahan, and G.W. Minshall. 1983. Methods for evaluating stream,
riparian, and biotic conditions. US Forest Service, Intermountain Forest and Range
Experiment Station, General Techinical Report INT-138, Ogden, UT.
Rakes, P.L., J.R. Shute, and P.W. Shute. 1999. Reproductive behavior, captive breeding,
and restoration ecology of endangered fishes. Environmental Biology of Fishes
55:31–42.
Rakes, P.L., M.A. Petty, J.R. Shute, C.L. Ruble, and H.T. Mattingly. 2013. Spawning and
captive propagation of Blackside Dace, Chrosomus cumberlandensis. Southeastern
Naturalist 12(Special Issue 4):162–170.
Starnes, L.B., and W.C. Starnes. 1981. Biology of the Blackside Dace Phoxinus cumberlandensis.
American Midland Naturalist 106:360–372.
Starnes, W.C., and L.B. Starnes. 1978. A new cyprinid of the genus Phoxinus endemic to
the Upper Cumberland River drainage. Copeia 1978:508–516.
Sutherland, A.B. 2007. Effects of increased suspended sediment on the reproductive success
of an upland crevice-spawning minnow. Transactions of the American Fisheries
Society 136:416–422.
Sutherland, A.B., and J.L. Meyer. 2007. Effects of increased suspended sediment on
growth rate and gill condition of two southern Appalachian minnows. Environmental
Biology of Fishes 80:389–403.
Sutherland, A.B., J. Maki, and V. Vaughan. 2008. Effects of suspended sediment on
whole-body cortisol stress response of two southern Appalachian minnows, Erimonax
monachus and Cyprinella galactura. Copeia 2008:234–244.
Wagner, B.K., C.A. Taylor, and M.D. Kottmyer. 2010. Status and distribution of Orconectes
williamsi (Williams’ Crayfish) in Arkansas, with new records from the Arkansas
River drainage. Southeastern Naturalist 9 (Special Issue 3) :175–184.
Wood, P.J., and P.D. Armitage. 1997. Biological effects of fine sediment in the lotic environment.
Environmental Management 21:203–217.
Wood, P.J., and P.D. Armitage. 1999. Sediment deposition in a small lowland stream:
Management implications. Regulated Rivers: Research and Management 15:199–210.
