Loss of Eelgrass in Casco Bay, Maine, Linked to Green Crab
Disturbance
Hilary A. Neckles*
Abstract - Over half of the Zostera marina (Eelgrass) cover disappeared from Casco Bay,
ME, largely between 2012 and 2013. Eelgrass decline coincided with a population explosion
of the invasive crab Carcinus maenas (European Green Crab). Green Crabs have been
found to damage Eelgrass in Atlantic Canada through foraging activity, but destruction
of established beds had not been documented in Maine. My objective was to determine
whether loss of Eelgrass from Casco Bay was related to Green Crab disturbance. In September
2013, I transplanted Eelgrass shoots inside and outside of replicate Green Crab
exclosures in a formerly vegetated area of upper Casco Bay. Following 26 d, mean survival
of Eelgrass inside the exclosures was 82% and outside the exclosures was 24%. The mean
plastochrone interval (time between formation of 2 successive leaves) of undamaged shoots
was the same inside and outside the exclosures, and was comparable to published values
from healthy Eelgrass beds in New England. Results implicate Green Crab bioturbation as
a leading cause of Eelgrass loss from this system.
Introduction
Zostera marina L. (Eelgrass) forms extensive meadows in coastal and estuarine
waters throughout New England and Atlantic Canada (Short and Short 2003).
Ranked among the most productive plant communities on the planet, Eelgrass is
valued as critical habitat for many ecologically and economically important fish
and shellfish species (Moore and Short 2006, Orth et al. 2006a). Waterfowl, wading
birds, and shore birds also depend on the rich food resources found in Eelgrass beds
(Erwin 1996, Seymour et al. 2002). Like other seagrass species, Eelgrass also absorbs
nutrients, baffles waves and currents, stabilizes bottom sediments, and serves
as a natural and highly efficient carbon sink while buffering the local pH environment
(Hendriks et al. 2014, Mcleod et al. 2011, Orth et al. 2006a). Because of these
diverse ecological functions, loss of Eelgrass can have wide-ranging consequences,
including reduced fish and wildlife populations, degraded water quality, increased
shoreline erosion, and reduced capacity to remove anthropogenic carbon dioxide
emissions and mitigate impacts of ocean acidification (Duarte 2002, Duarte et al.
2013, Greiner et al. 2013, Orth and Moore 1983).
Eelgrass occurs in the low intertidal and shallow subtidal zones along much
of Maine’s shoreline (MDMR 2012). Historically, Eelgrass reached one of its
greatest statewide extents in Casco Bay, located in southern Maine (Fig. 1). Mapping
based on aerial photography acquired in 2001 and 2002 showed 3338 ha of
Eelgrass in Casco Bay (CBEP 2005). Much of the Eelgrass occurred in the broad
*USGS Patuxent Wildlife Research Center, 196 Whitten Road, Augusta, ME 04330;
hneckles@usgs.gov.
Manuscript Editor: Thomas Trott
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
479
intertidal and subtidal flats of the upper bay; the intertidal meadows represented
some of the largest expanses of intertidal Eelgrass in the western North Atlantic
(Short and Short 2003). In July of 2013, a dramatic loss of Eelgrass was discovered.
Remapping from aerial photography acquired in August 2013 revealed only
Figure 1. Study area in Casco Bay, ME, showing distribution of Eelgrass based on aerial
photography acquired in 2001 and 2002 (crosshatched; MDMR 2012) and in August 2013
(shaded; Barker 2013, MDEP 2013). Where 2013 coverage is mapped, it overlays and
largely coincides with the 2001/2002 distribution. The Eelgrass persisting in Maquoit Bay
in 2013 was mapped at less than 10% cover (MDEP 2013). The arrow at Cousins Island points to
the Eelgrass collection site.
Northeastern Naturalist
480
H.A. Neckles
2015 Vol. 22, No. 3
1477 ha of Eelgrass in all of Casco Bay (Barker 2013, MDEP 2013), with nearly
complete loss of Eelgrass from the bay’s uppermost reaches (Fig. 1). Reconstruction
of local observations indicated a rapid Eelgrass decline that occurred largely
between 2012 and early 2013.
The near-complete disappearance of Eelgrass from upper Casco Bay coincided
with a population explosion of the invasive crab, Carcinus maenas (L.) (European
Green Crab, hereafter, Green Crab), in Casco Bay and other areas of the Maine
coast (MDMR 2013, Webber 2013). The Green Crab was introduced to New York
and southern New England in the early 1800s, and by the early 1900s had expanded
its range northward to Casco Bay (Scattergood 1952). Dramatic increases in Gulf
of Maine Green Crab populations in the 1930s, 1950s, and 1970s occurred during
periods of sea-surface temperature warming, with subsequent population declines
following unusually cold winters (Berrill 1982, Welch 1968). In the early 1950s,
precipitous declines in populations of Mya arenaria L. (Soft-shell Clam) in New
England were correlated with the increased abundance of Green Crabs (Glude
1955, Ropes 1968, Welch 1968). The most recent Green Crab population boom in
Maine was similarly associated with warmer sea-surface temperatures (Beal 2014,
MDMR 2013). Although no Green Crab monitoring was in place in Casco Bay in
2012 and early 2013, shellfish harvesters and Maine shellfish managers reported
extremely high Green Crab densities in near-shore coastal habitat (Beal 2014; J.K.
Kanwit, ME Department of Marine Resources and Chair of the Governor’s Task
Force on the Invasive European Green Crab, Augusta, ME). In 2013, Soft-shell
Clam surveys in various locations in upper Casco Bay documented depleted Softshell
Clam stocks and virtual absence of small individuals of young age-classes
(Beal 2014, Devereaux 2013, MER Assessment Corporation 2013), a pattern that
was also observed in the 1950s resulting from intensive Green Crab predation
(Glude 1955). In an area of ~50 ha in upper Casco Bay (in the Harraseeket River,
South Freeport, ME), a 2013 trapping study conducted from late May to early November
yielded a total of 5939 kg of Green Crabs from 300 hauls, with an average
catch per trap of 4.7 kg (Beal 2014). A 24-h, statewide Green Crab trapping survey
that was coordinated by the Maine Department of Marine Resources on 1 August
2013 yielded catch rates per trap of up to 181 Green Crabs from Casco Bay locations
(Webber 2013).
Green Crabs are known to damage and uproot Eelgrass shoots while digging
in the sediment for benthic prey (Davis et al. 1998, Malyshev and Quijón 2011),
and juveniles may also cut off shoots while grazing directly on Eelgrass meristems
(Malyshev and Quijón 2011). Such foraging activity by high densities of Green
Crabs has been shown to cause drastic declines of Eelgrass from some bays in Nova
Scotia, Canada (Garbary et al. 2014, MTRI and Parks Canada 2014). At the time of
Eelgrass disappearance from Casco Bay, destruction of established beds by Green
Crabs had not been documented in Maine. However, I recovered Eelgrass shoots
from the shoreline of upper Casco Bay with clipped and frayed bases characteristic
of Green Crab damage (Fig. 2; cf., Davis et al. 1998, Garbary et al. 2014), suggesting
Green Crabs as a local source of disturbance. Thus, the goal of this study was
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
481
to determine whether Green Crab bioturbation may have caused the loss of Eelgrass
in upper Casco Bay.
The lack of data on Green Crab densities in upper Casco Bay during the Eelgrass
decline hindered direct tests of the potential effects of Green Crab activity on
Eelgrass disappearance. Therefore, in September 2013, I conducted a field experiment
to test whether environmental conditions in upper Casco Bay would support
Eelgrass growth in the absence of Green Crab disturbance. I transplanted Eelgrass
shoots from a persistent bed in mid-Casco Bay to locations inside and outside
of protective crab-exclosures in a formerly vegetated site in the upper bay, and
Figure 2. Eelgrass
shoots collected from
the shoreline of upper
Casco Bay on
30 July 2013 and 12
August 2013 with
clipped (top photos)
and frayed (bottom
photos) bases characteristic
of Green Crab
damage.
Northeastern Naturalist
482
H.A. Neckles
2015 Vol. 22, No. 3
harvested the plants after a 26-d growth interval. A comparison of Eelgrass growth
and survival between protected and unprotected treatments provided indirect evidence
for the role of Green Crabs in decline of Eelgrass habitat in upper Casco Bay.
Field-Site Description
This experiment was conducted in Maquoit Bay, which is the uppermost embayment
of western Casco Bay (Fig. 1). Maquoit Bay is a shallow estuary encompassing
1013 ha with broad intertidal and subtidal flats and a narrow central channel. The
tidal range is approximately 4 m, and bottom sediments are predominantly mud
(clay and silt; Kelley et al. 1987, Larsen et al. 1983, Neckles et al. 2005). Historically,
Eelgrass extended continuously from the low intertidal zone to depths of
about 3 m below mean low water (MLW). In 2001, there were 570 ha of Eelgrass
mapped in Maquoit Bay (Neckles et al. 2005), and aerial photographs acquired in
November 2009 showed little change in Eelgrass distribution up to that time (CBEP
2010). Most of the Eelgrass in Maquoit Bay was mapped at 70–100% cover in 2001
(MDMR 2012). Although there were no formal assessments of Eelgrass coverage
between 2009 and the discovery of denuded sediments throughout upper Casco Bay
in July 2013, local observations by shoreline residents, shellfish harvesters, town
officials, and a college biology class pinpointed the most substantial Eelgrass loss
in Maquoit Bay as occurring from summer 2012 into early 2013. Mapping from
aerial photographs acquired in August 2013 revealed that only 96 ha of Eelgrass
remained (Fig. 1), all of which occurred at less than 10% cover (MDEP 2013).
I installed experimental exclosures in the cove north of Little Flying Point in
southwestern Maquoit Bay (Fig. 1). In 2009, the Eelgrass bed had covered the
entire cove (CBEP 2010), but in July 2013 the cove was completely devoid of vegetation.
I placed the exclosures in the shallow subtidal zone at a depth of about 0.3
m below MLW. The seawater salinity was 30 ppt and the bottom sediments were
uniformly mud.
Methods
Experimental design
I planted Eelgrass shoots in plots that were either protected (inside exclosures)
or unprotected (outside exclosures) from potential Green Crab disturbance. I established
3 replicates of each type of plot along a 33.2-m transect that was 340 m from
shore and parallel to the shoreline, so that all plots were at similar depths (Fig. 3A).
The protected plots were inside square crab-exclosures that were 12 m apart along
the transect, and the unprotected plots were located 2 m outside of the exclosures
along the same transect. I marked each unprotected plot with a single wooden stake.
The exclosures were framed with lumber (2 x 4s); the side panels were 0.46 m
tall, 2.4 m wide, and constructed with corner posts that extended 0.46 m below the
bottom of the frame. The side walls were rigid plastic mesh with 0.5-cm openings.
I anchored the exclosures in place by driving the corner posts into the mud so that
the bottom of exclosure frame lay in the sediment. To prevent Green Crabs from
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
483
climbing into the exclosures, I attached a 15-cm strip of aluminum flashing to the
top of each wall and bent it outwards at an angle, essentially forming a downwardopening
pocket around the exclosure rim. To prevent Green Crabs from burrowing
into the exclosures, I staked a 25-cm-wide strip of plastic mesh flat onto the sediment
surface along the outside border of each wall.
I installed the exclosures in the field on 23 August 2013, and allowed them to
stabilize for 12 d before I transplanted the Eelgrass shoots into the experimental
plots. The growth experiment extended from 5 September 2013 to 1 October 2013
(26 d). I monitored Green Crabs at the study site as catch per unit effort using crab
traps deployed continuously from 23 August to the end of the experiment. I set a
crab trap inside each exclosure (Fig. 3B) and set 2 traps outside the exclosure array
(Fig. 3A). The traps were rectangular (71 cm x 30 cm x 30 cm) with a single opening
(8 cm x 13 cm). They were constructed of plastic-coated steel wire and heavy
enough to stay in place on the substrate without weights. At the beginning of the
pre-experimental stabilization period, I baited the traps with equal amounts of Softshell
Clams and groundfish-processing waste—bodies with filets removed, heads,
and skins of Melanogrammus aeglefinus (L.) (Haddock), Gadus morhua L. (Atlantic
Cod), and Pollachius virens (L.) (Pollack). Green Crab monitoring during this
period served to determine the effectiveness of the exclosures in preventing crab
entry. To minimize attracting Green Crabs into the exclosures during the growth
experiment, I discarded all bait remaining in all the traps when the Eelgrass was
transplanted into the experimental plots. In addition to documenting the abundance
of Green Crabs as a potential disturbance to Eelgrass, trapping during the growth
experiment was an effort to confine Green Crabs that entered the exclosures away
from the Eelgrass plants. I removed and counted all Green Crabs from the traps
twice per week, and cleaned any accumulated sediment off the mesh walls of the
exclosures with a scrub brush.
Eelgrass transplanting
I collected Eelgrass shoots on 4 September 2013 from a persistent bed off Cousins
Island in mid-Casco Bay, which was the closest extensive, dense Eelgrass bed to
the study site (Fig. 1). I collected shoots from the shallow subtidal zone at a depth
comparable to that at the exclosure location. I gently uprooted ~120 shoots by hand
with 3–5 cm of rhizome intact (Davis and Short 1997). Maintaining Eelgrass at low
salinities minimizes potential infection and spread of wasting disease (caused by
the naturally-occurring slime mold Labyrinthula zosterae Porter and Muehlstein)
in the collected shoots (Burdick et al. 1993); therefore, I diluted seawater from the
collection site with distilled water to 12 ppt as a storage medium. I transported and
stored the plants overnight in a large tub of aerated, diluted seawater at 20 °C.
I prepared Eelgrass planting units and transplanted them into the experimental
field sites on 5 September 2013, using a modification of the horizontal-rhizome
transplant method (Davis and Short 1997). During preparation of the planting units,
I gradually added seawater from the collection site to the Eelgrass storage medium to
increase the salinity to the ambient field strength; the salinity was adjusted from 12
Northeastern Naturalist
484
H.A. Neckles
2015 Vol. 22, No. 3
ppt to 30 ppt over 6 h. A planting unit consisted of 5 pairs of shoots attached to a 50-
cm length of 0.95-cm diameter steel reinforcing bar; thus, each planting unit had 10
shoots. I attached shoot pairs to the bar with plastic cable ties at 10-cm intervals with
the rhizomes aligned parallel to the bar and pointing in opposite directions. Eelgrass
Figure 3. Design of the field experiment. (A) Position of exclosures (squares) and unprotected
sites (black circles) along a transect 340 m from shore. Stars represent locations
of Green Crab traps set outside of the exclosures. Size of circles and stars is not to scale.
(B) Detail of a single exclosure showing the position of planting units (dashed lines) and
Green Crab trap. The trap opening is on the short side of the trap facing towards the inside of
the exclosure.
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
485
grows by successive formation of leaves at identifiable nodes along the rhizome and
lengthening of the rhizome sections between the nodes, termed the internodes (Duarte
et al. 1994). I fastened shoots to the bar at a point immediately distal to the second
complete rhizome node; thus, each shoot had 1 complete rhizome segment (node plus
internode) between the basal leaf/rhizome meristem and the cable tie. In this way, the
cable ties served effectively as rhizome tags for identifying new rhizome tissue produced
during the experiment (Short and Duarte 2001).
I transplanted the Eelgrass planting units at the study site 24 h after initial shoot
collection. Three planting units were assigned haphazardly to each experimental
plot; thus, the experimental design consisted of 3 replicate plots of each treatment
(protected and unprotected), with 3 subsamples (Eelgrass planting units) per plot. I
installed the planting units by pressing the bars and attached rhizomes into the top 2
cm of the sediment and anchoring the ends of the bars to the substrate with U-shaped
wire staples. I installed the planting units parallel to one another and 25 cm apart, so
that the 3 planting units occupied a 50 cm x 50 cm square (Fig. 3B). The planting units
inside the exclosures were 0.95 m away from the walls in all directions.
Eelgrass measurements
I observed the condition of the Eelgrass planting units after 10 d and 19 d of
growth by snorkeling over the planting units at low tide. At the end of the experiment
I harvested all planting units for quantitative analysis. I measured survival of
individual planting units as the proportion of the original 5 pairs of Eelgrass shoots
with at least 1 shoot remaining. I assessed planting-unit survival using an analysis
of variance for subsampling model, with treatment effects determined using the
experimental error, and employed residual analysis to confirm that the basic assumptions
of analysis of variance were met (Kutner et al. 2004) .
I used only undamaged Eelgrass shoots to test whether environmental conditions
in upper Casco Bay would support Eelgrass growth in the absence of Green
Crab disturbance. I assessed all surviving shoots for the presence of clipped
leaves or shredding along the leaf axis, which would characterize Green Crab
damage (Fig. 2). For all undamaged shoots, I recorded the total number of complete
rhizome segments present between the meristem and the cable tie. To decide
whether all undamaged shoots could be pooled for reporting purposes, I used a
t-test to determine whether there was a difference in the number of rhizome segments
in front of the cable tie between shoots growing inside and outside the
exclosures. For each undamaged shoot, I calculated the minimum and maximum
number of new rhizome segments that could have been produced during the experimental
growth interval; the range in the potential number of new segments
on a given shoot accommodated an unknown amount of rhizome tissue present
between the first rhizome node and the shoot meristem on planting (Day 0),
which varied among shoots from almost indiscernible to almost the length of a
full internode. The potential maximum number of new rhizome segments produced
during the experiment equaled the total number of segments in front of the
cable tie (i.e., between the cable tie and the meristem) at harvest (Day 26) minus
Northeastern Naturalist
486
H.A. Neckles
2015 Vol. 22, No. 3
1, which accounted for the single complete rhizome segment in front of the cable
tie at Day 0 and no rhizome tissue present initially between the first node and the
meristem. The potential minimum number of new segments produced equaled
the total number of rhizome segments in front of the cable tie on Day 26 minus
2, which accounted for both the complete segment in front of the cable tie and a
nearly complete segment between the first node and the meristem on Day 0. In
Eelgrass, a new leaf is produced with each new rhizome segment (Duarte et al.
1994, Short and Duarte 2001); thus, I derived the plastochrone interval, or the
time interval (d) between the formation of 2 successive leaves on the shoot, as
the growth interval (26 d) divided by the number of new rhizome segments.
Environmental factors
I measured diffuse downwelling attenuation of photosynthetically available
radiation (PAR) at the study site twice during the growth experiment (15 and 28
September). I took measurements at the midpoint of the exclosure transect when
the water was about 1.25-m deep (on a falling tide on 15 September and a rising
tide on 28 September). I measured duplicate or triplicate profiles of downwelling
photosynthetic photon-flux density using a LI-192SA underwater quantum sensor
(LI-COR, Lincoln, NE) within 1.5 h of solar noon (Carruthers et al. 2001). I
made measurements every 20 cm from 10 cm below the water surface to about 25
cm above the ocean bottom; measurements at each depth were integrated over 15
sec. Simultaneous measurements of incident PAR were made using a LI-190SA
terrestrial quantum sensor (LI-COR) to account for any changes in incident solar
irradiance over the period of time needed to complete a full water-column profile. I
calculated the attenuation coefficient of downwelling PAR (Kd) as the slope of the
least squares regression relating ln (Iz/Iair) to depth in meters, where Iz is the irradiance
at depth z and I air is the incident irradiance in air.
At the end of the experiment I collected sediment samples from the center of
each experimental replicate. I collected samples from the top 10 cm of sediment using
a 2.5-cm-diameter syringe corer (i.e., a 60-cc syringe with the graduated tip cut
off flush with the zero volume mark); samples were frozen and stored for 2 months.
Prior to analysis, I thawed the samples under refrigeration and homogenized them.
I determined organic content by loss on ignition following combustion for 4 h at
450 °C (Erftemeijer and Koch 2001), and employed a t-test to compare the mean
organic content of the sediments in the protected and unprotected plots.
I continuously measured water temperature at the study site throughout the
experiment using an Onset TidbiT®v2 temperature logger (Onset Corporation,
Bourne, MA) attached to a stake installed at the end of the exclosure transect;
temperature was recorded at 30-min intervals. The logger was near the bottom of
the water column so that it remained submerged during the study period. Eelgrass
die-offs in some areas have been associated with sustained high water temperatures
(Moore et al. 2014, Nejrup and Pedersen 2008, Reusch et al. 2005); thus, I derived
the maximum daily water temperatures in Casco Bay during July and August, 2002–
2012 from continuous data recorded at the National Oceanic and Atmospheric
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
487
Administration tide station in Portland, ME (NOAA CO-OPS 2013). The station is
located at the southern end of Casco Bay (43°39'24''N, 70°14'48''W), at the end of
the Maine State Pier. Temperature was recorded at 6-min intervals at a depth 3.4 m
below mean lower low water. I created cumulative percentage distributions of daily
high water temperatures during July and August from frequencies within 1-degree
bins. In addition, I interviewed citizens residing along the shoreline of upper Casco
Bay regarding observations of potential physical disturbance to Eelgrass during
2012 and early 2013.
Results
Effectiveness of exclosures
I captured an order of magnitude more Green Crabs in baited traps that were deployed
outside the exclosures than inside the exclosures during the pre-experimental
period (Table 1). Thus the exclosures limited, but didn’t completely prevent, Green
Crab access. Continuous monitoring with unbaited traps during the experimental
period showed that Green Crabs persisted in the study area throughout the growth
experiment, and that even the Eelgrass planting units protected by the exclosures
were potentially subjected to some level of Green Crab disturbance (Table 1). There
was no discernible evidence of exclosure influence on water flow in the protected
sites; during biweekly site-visits I observed the shoots inside and outside the exclosures
to be bent at similar angles, and there were no visible differences between
treatments in the level of sediment accumulated on the leaves.
Eelgrass survival and growth
Preliminary observations revealed early differences in Eelgrass survival inside
and outside the exclosures. After 10 d of growth, each of the protected planting
units still had 5 pairs of shoots, whereas most of the unprotected planting units
had ≤2 pairs of shoots. Some shoot bases with the leaves clipped off were evident
Table 1. Responses by Green Crabs and Eelgrass inside and outside of experimental exclosures. #/baited
trap = total number of Green Crabs caught per baited trap during pre-experimental period (n = 3 inside,
n = 2 outside); #/unbaited trap = total number of Green Crabs caught per unbaited trap during experimental
period (n = 3 inside, n = 2 outside); # undamaged shoots = total number of surviving shoots that
were undamaged (out of initial 90 shoots per treatment); # damaged shoots = total number of surviving
shoots that showed evidence of Green Crab damage (out of initial 90 shoots per treatment). Values for
Green Crabs are mean (range) of total number caught per trap in individual traps deployed continuously
during the pre-experimental period (23 August–5 September) and the experimental period (5 September–
1 October); values for planting-unit survival are mean ± SE; values for undamaged and damaged
shoots are total counts across all replicates.
Protected plots Unprotected plots
inside exclosures outside exclosures
#/baited trap 27 (22–32) 242 (213–272)
#/unbaited trap 17 (9–30) 34 (31–37)
Planting-unit survival (%) (n = 3 plots per treatment) 82 ± 14 24 ± 14
# undamaged shoots 47 10
# damaged shoots 10 5
Northeastern Naturalist
488
H.A. Neckles
2015 Vol. 22, No. 3
among the unprotected planting units. By 19 d of growth, nearly all of the protected
planting units still had ≥4 shoot pairs, whereas some of the unprotected planting
units were devoid of vegetation. At the end of the experiment, survival of the
planting units in the protected plots in the exclosures was more than 3 times that of
the planting units that were unprotected from Green Crabs outside the exclosures
(Table 1; F = 7.86, P = 0.049), and most of the surviving shoots that showed no sign
of Green Crab damage were inside the exclosures (Table 1). Where shoots were
missing from the planting units, rhizomes with clipped-off shoots or shoot bases
with clipped-off leaves were often still attached.
There was no difference in the mean number of rhizome segments in front of
the cable tie between undamaged shoots from within (4.2 ± 0.1 SE) and outside
(3.8 ± 0.2 SE) the exclosures (t = 1.62, P = 0.111), thus I pooled all 57 undamaged
shoots (Table 1) for subsequent analysis. The undamaged shoots produced a mean
maximum of 3.1 (± 0.1 SE) and a minimum of 2.2 (± 0.1 SE) new rhizome segments
during the 26-d growth interval, which corresponded to a mean plastochrone
interval of 8.8 d (± 0.3 SE) to 14.1 d (± 0.9 SE) (T able 2).
Environmental factors
The attenuation of downwelling PAR measured during the growth experiment
varied from 0.63 m-1 (mean of 2 profiles on 15 September) to 0.73 m-1 (mean of 3
profiles on 28 September), resulting in 23–19% of solar PAR insolation available
at the transplant depth at mid-tide (i.e., a depth of 2.3 m). The average daily seawater
temperature dropped from 18.4 °C to 15.4 °C from 6–17 September, and then
remained at about 15 °C through harvest on 1 October. The maximum seawater
temperature recorded during the growth experiment was 20.8 °C and the minimum
was 13.2 °C. The sediment organic content was 4.9% (± 0.04 SE) inside the exclosures
and 4.6% (± 0.35 SE) at the unprotected sites outside the exclosures, with no
significant difference between experimental treatments (t = 0.71, P = 0.550).
The median daily high water temperature recorded during July and August
at the Portland, ME, monitoring station ranged from 15.3 °C in 2004 to 19.0 °C
in 2012 (Table 3). There was considerable overlap of the cumulative percentage
distributions of summertime daily high temperatures from 2003 through 2009, so
alternate years are presented within this range for clarity (Fig. 4). During 2011 and
Table 2. Mean Eelgrass plastochrone interval (time interval between the formation of 2 successive
leaves on a shoot) measured at locations in New England during September.
Plastochrone
Location Growth period(s) interval (days) Reference
Maquoit Bay, Freeport, ME Single growth period (26 d) 8.8–14.1 This study
in September 2013
Fishing Island, Kittery, ME Two growth periods (18 d, 19 d) 12.6–15.5 Gaeckle and
in September 2000 Short (2002)
Waquoit Bay, MA Single growth period (27–36 d) 10.1–15.3 Hauxwell et al.
in September 1998, (2006)
in each of 4 estuaries
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
489
2012, a greater percentage of days reached higher temperatures than during earlier
years. The maximum temperatures were recorded in 2012, with the daily high temperature
reaching between 20 °C and 21 °C on 5 days.
Discussion
Loss of Eelgrass from Casco Bay
Eelgrass survival in Maquoit Bay was enhanced substantially by protection
from Green Crabs. As evidenced by the capture of some Green Crabs inside the
Table 3. Median daily high temperature of seawater recorded during July and August at the NOAA tide
station at the southern end of Casco Bay. Eelgrass was present throughout the bay from 2002 through
at least 2010, and the major Eelgrass loss occurred from 2012 through early 2013.
2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012
Median daily high temp (ºC) 17.0 15.6 15.3 15.8 15.7 15.7 16.2 15.9 16.9 18.0 19.0
n 39 62 62 62 61 61 62 62 62 55 62
Figure 4. Cumulative percentage distributions of summertime (July–August) daily high
temperatures of seawater measured at the NOAA tide station at the southern end of Casco
Bay during selected years. Plots indicate the percentage of days in July and August with
daily high temperatures above the values indicated along the x-axis.
Northeastern Naturalist
490
H.A. Neckles
2015 Vol. 22, No. 3
exclosures during the experimental growth period (Table 1), the exclosure fencing
did not isolate Eelgrass completely from potential disturbance; a proportion
of the surviving shoots and many of the remnant bases of shoots that were lost
from inside and outside the exclosures showed characteristic signs of Green Crab
damage. Thus, it is likely that disappearance of the planting units within both
treatments was caused by Green Crab disturbance. The plastochrone interval I
measured on Eelgrass shoots that were not subject to Green Crab disturbance was
comparable to published values from healthy Eelgrass beds in New England measured
at the same time of year (Table 2). These results showed that in the absence
of Green Crab disturbance, environmental conditions in Maquoit Bay following
the extensive Eelgrass decline remained conducive to at least short-term growth
and survival of Eelgrass.
Although Eelgrass is susceptible to various natural and anthropogenic disturbances
(Orth et al. 2006a, Short and Wyllie-Echeverria 1996), multiple lines of
evidence ruled out other acute environmental factors as causing Eelgrass loss in
upper Casco Bay. For example, the most prevalent cause of seagrass loss worldwide
is cultural eutrophication and consequent reduction in the amount of light
available for seagrass photosynthesis (Burkholder et al. 2007, Waycott et al. 2009).
An early sign of reduced light penetration to seagrass leaves is a decrease in the
seagrass depth limit (Borum 1996, Dennison 1987, Sand-Jensen and Borum 1991).
In Maquoit Bay, the depth limit of the Eelgrass meadow increased between 1993
and 2001 (Neckles et al. 2005) and then remained stable through 2009 (CBEP
2010), and in 2013 the only Eelgrass remaining was a small patch, albeit sparse,
that extended to the deepest bed contour (Fig. 1); these temporal and spatial patterns
are inconsistent with reduced light availability stemming from watershed
inputs. Eutrophication can also lead to sediment organic enrichment and ultimate
accumulation of phytotoxic sulfides with deleterious effects on Eelgrass (Holmer
and Laursen 2002, Koch 2001, Mascaró et al. 2009), but the sediment organic content
measured during this study within an area of Maquoit Bay that lost Eelgrass
(4.6–4.9%) was unchanged from that measured at the same site in 2000, prior to the
Eelgrass decline (4.8–5.4%; H. Neckles, unpublished site-means in the cove north
of Little Flying Point that contributed to the bay-wide range of 4.0–5.8% reported
in Neckles et al. 2005). There were no reports of any major direct physical disturbance
to Eelgrass from either anthropogenic (e.g., trawling or dragging activity) or
natural (e.g., storms or ice scour) activities during the period of vegetation loss (D.
Devereaux, Brunswick Department of Marine Resources and Harbor Management,
Brunswick, ME, pers. comm.). I also found no evidence of significant Eelgrass
wasting disease (i.e., infection of younger inner leaves; Burdick et al. 1993) on any
plants washed up on the shore of upper Casco Bay or in the persistent Eelgrass bed
from which I collected experimental shoots.
High water-temperatures can adversely impact Eelgrass metabolism, causing
reductions in photosynthetic performance (Evans et al. 1986, Nejrup and Pedersen
2008, Winters et al. 2011), ratio of photosynthesis to respiration (Marsh et al.
1986), meristematic oxygen content (Greve et al. 2003), and shoot density and
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
491
growth (Bergmann et al. 2010, Bintz et al. 2003, Ehlers et al. 2008, Nejrup and
Pedersen 2008). Consequently, Eelgrass declines have been documented following
even fairly short-term exposure to unusually high summer temperatures (Moore
and Jarvis 2008, Moore et al. 2014, Reusch et al. 2005). The temperature thresholds
associated with loss of Eelgrass cover vary with latitude: studies in northern Europe
found reduced Eelgrass growth after 6 weeks at temperatures above 20 °C (Nejrup
and Pedersen 2008) and a 44% reduction in shoot density after 4 weeks at 25 °C
(Ehlers et al. 2008), and studies in southern Virginia reported Eelgrass die-offs
following 1- to 2-week exposures to temperatures above 28 °C (Moore and Jarvis
2008, Moore et al. 2014). Although summertime water temperatures in Casco Bay
reached higher daily maxima during the Eelgrass decline in 2012 than in earlier
years when Eelgrass persisted throughout the bay, the 2012 temperatures rarely
exceeded 20 °C and did not approach the thresholds shown to cause Eelgrass loss
in northern waters (Fig. 4).
Taken in concert, the accumulation of clipped and shredded shoots indicative
of Green Crab damage along the shoreline of upper Casco Bay, the growth and
survival of Eelgrass during this experiment when Green Crabs were excluded, the
observed destruction of Eelgrass in my experimental plots in a manner consistent
with Green Crab damage, and negative evidence regarding other major potential
threats to Eelgrass in Casco Bay implicate Green Crab bioturbation as a leading
cause of Eelgrass loss from this system. Disney et al. (2014) also reported loss of
an Eelgrass bed in Frenchman Bay, off Mt. Desert Island, ME, between 2012 and
2013 that coincided with the coast-wide increase in Green Crab populations.
Although acute effects of other potential stresses on Eelgrass in Casco Bay,
such as toxic compounds (Short and Wyllie-Echeverria 1996) or unknown pathogens,
seem unlikely, they cannot be ruled out, nor can potential interactive effects
of various environmental stressors. For example, although the median light availability
to the Eelgrass transplants measured during this experiment (19–23% of
surface irradiance at mid-tide) exceeded the minimum light requirements reported
for Eelgrass (10–20% of surface irradiance; Duarte 1991, Moore et al. 1997, Olesen
and Sand-Jensen 1993), local observations suggested that turbidity in Maquoit Bay
increased following the loss of Eelgrass, presumably due to resuspension of the fine
bottom sediments (D.R. Devereaux, Brunswick Department of Marine Resources
and Harbor Management, Brunswick, ME, and P.J. Horne, Freeport, ME, pers.
comm.). The magnitude of underwater light attenuation during the Eelgrass decline
is unknown, but it is possible that Green Crab bioturbation may have increased
the concentration of suspended sediments in the system and accelerated the loss
of Eelgrass through decreased light availability. In a Gulf of St. Lawrence estuary
in Nova Scotia, Garbary et al. (2014) observed that in addition to increasing local
turbidity, sediment resuspended by Green Crab foraging activity was also deposited
heavily on Eelgrass leaves, where it contributed to further light reduction. In
addition, warmer water temperatures are known to exacerbate the effects of light
reduction on Eelgrass (Bintz et al. 2003, Moore et al. 2014, Neckles et al. 1993,
Olesen and Sand-Jensen 1993). Thus, although the 2012 water temperatures did
Northeastern Naturalist
492
H.A. Neckles
2015 Vol. 22, No. 3
not appear high enough to be the primary cause of Eelgrass loss, water temperature
may have influenced Eelgrass response to presumed turbidity increases. There is a
relative paucity of information on the simultaneous influences of multiple stressors
on seagrasses (Orth et al. 2006a), and whether various factors may have enhanced
the effects of Green Crabs or combined to cause Eelgrass loss is unknown.
The conclusion that Green Crabs were a primary cause of Eelgrass disappearance
from Casco Bay is consistent with their documented role in causing dramatic
declines of Eelgrass from some bays on Nova Scotia’s Gulf of St. Lawrence (Garbary
et al. 2014) and Atlantic (MTRI and Parks Canada 2014) coasts in the early to
mid-2000s. There are distinct differences, however, between the Eelgrass–Green
Crab relationships observed in Nova Scotia and Casco Bay. Genetic evidence
indicates that Green Crab populations in the northwest Atlantic were established
through multiple invasions from Europe (Blakeslee et al. 2010, Roman 2006). The
Green Crabs first introduced to New York and southern New England in the early
1800s most likely originated from western Europe (Darling et al. 2008, Roman
2006). Populations expanded northward up the coast of New England and around
the Bay of Fundy, reaching Nova Scotia’s Atlantic coast by the mid-1950s. In the
late 1980s or early 1990s, new genetic lineages were introduced to northern Nova
Scotia that most likely originated from northern Europe (Darling et al. 2008, Roman
2006). These new genotypes expanded rapidly north and west into the southern
Gulf of St. Lawrence and south along Nova Scotia’s Atlantic coast into the Gulf of
Maine (Pringle et al. 2011). The Green Crab destruction of Eelgrass that occurred
in Nova Scotia estuaries was caused by the new invasion from northern Europe into
areas either where Green Crabs did not yet exist (Gulf of St. Lawrence, Garbary et
al. 2014) or where only Green Crabs of the historical (western European) lineage
had existed previously (Little Port Joli and St. Catherine’s Estuaries on the Atlantic
coast, McCarthy 2013). Based on intra- and interspecific competition experiments
in the Canadian Maritime Provinces, Rossong et al. (2012) suggested that the
foraging ability of the recent northern-European lineages of Green Crabs may be
superior to that of the long-established historical lineage, and that both time since
establishment and genetic traits may influence the effects of Green Crabs on native
habitats. Although the northern Green Crab genotypes are expected to continue
expanding southward in the Gulf of Maine with the Gulf of Maine Coastal Current
(Pringle et al. 2011), their southern limit in 2013 was Mt. Desert Island, ME; the
northern lineages had not yet appeared in Casco Bay (Williams et al. 2015). Thus
the destruction of Eelgrass habitat in Casco Bay was associated with a population
explosion of the historical Green Crab genetic lineage. Davis and Short (1997)
observed Green Crab bioturbation of transplanted Eelgrass in New Hampshire, but
the loss of Eelgrass in Casco Bay represents the first documentation of damage to
natural beds by the historical Green Crab lineage. Green Crab disturbance of Eelgrass
in its native Europe, where Green Crab populations appear to be regulated by
parasites (Torchin et al. 2001), has not been reported, nor am I aware of impacts to
Eelgrass along other coasts where Green Crab invasions overlap Eelgrass distribution
(west coast of North America, Japan).
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
493
Although a tremendous variety of Green Crab prey items have been identified,
bivalve mollusks often dominate their diet (Cohen et al. 1995, Glude 1955, Grosholz
and Ruiz 1995, 1996, Klassen and Locke 2007, Ropes 1968). Indeed, the
recent Green Crab population explosion in coastal Maine has been deemed a severe
threat to the state’s present-day Soft-shell Clam industry (MDMR 2013, Webber
2013). The range of sediment disturbance caused by Green Crab foraging varies
from the top few centimeters to pits 10 cm–15 cm deep (Cohen et al. 1995, Garbary
et al. 2014), and Green Crab impacts on prey are greatest in soft-bottom habitats
(Klassen and Locke 2007). Both the fine-grained sediments in upper Casco Bay
(Kelley et al. 1987) and the broad distribution of Soft-shell Clams as a preferred
prey item (MDMR 2009) may have concentrated Green Crab digging activity in this
area. Garbary et al. (2014) observed that as sediments become loosened by Green
Crab foraging, Eelgrass shoots become easily dislodged; thus, the fine sediments
in upper Casco Bay may have further increased Eelgrass susceptibility to Green
Crab disturbance. By the time of my exclosure experiment in 2013, Green Crab
predation had depleted much of the bivalve food resource in Maquoit Bay (pers.
observ.), but Nassarius obsoletus (Say) (Mud Snail; formerly Ilyanassa obsoleta
[Say]; ITIS 2015) was extremely abundant; Mud Snails are common prey of Green
Crabs (Schwab and Allen 2014) and the high Mud Snail density could explain the
continued crab activity in Maquoit Bay. Green Crabs are known to disturb Eelgrass
transplants during restoration projects (Davis and Short 1997), and the disturbance
to the unprotected Eelgrass shoots outside my exclosures could have been caused
by Green Crabs foraging for benthic prey or by the direct grazing by juvenile Green
Crabs on Eelgrass meristems (Malyshev and Quijón 201 1).
Implications for Eelgrass recovery
Recovery of the Eelgrass meadows in upper Casco Bay will depend on processes
controlling Eelgrass recruitment, survival, and growth. Natural Eelgrass revegetation
following large-scale declines occurs through germination and survival
of seedlings to form new patches and subsequent lateral expansion of patches by
vegetative propagation (Greve et al. 2005, Harwell and Orth 2002a, Olesen and
Sand-Jensen 1994). In the early 2000s in Maquoit Bay, the mean rate of newpatch
recruitment into a 32-ha scar in the existing Eelgrass meadow that had been
denuded by commercial dragging for Mytilus edulis L. (Blue Mussel) was 0.19
patches m-2 yr-1, a rate comparable to published values from other systems (Neckles
et al. 2005). At that time, the denuded drag scar was surrounded by dense Eelgrass
beds to provide a ready and abundant supply of seeds for recolonization, and aerial
photography 10 years post-dragging showed that Eelgrass in the former scar had
not yet reached 100% cover (J.W. Sowles, North Yarmouth, ME, unpubl. data).
In contrast, following the recent extensive loss of vegetation from most of upper
Casco Bay, the closest dense stand of Eelgrass to the midpoint of Maquoit Bay is 15
km away (northeastern limit of 2013 Eelgrass distribution; Fig. 1). Eelgrass seeds
can be transported long distances by floating reproductive shoots (Harwell and Orth
2002b), so the Eelgrass beds in lower Casco Bay should serve as a source of seeds
Northeastern Naturalist
494
H.A. Neckles
2015 Vol. 22, No. 3
for recolonizing upper Casco Bay. However, the rate of new-patch recruitment from
such distant seed sources would presumably be considerably lower than the rate
measured from adjacent beds, thus resulting in a slower recovery.
Eelgrass revegetation would likely be hastened substantially by restoration
(e.g., Orth et al. 2006b, Short et al. 2002). Recently, effective control of Green
Crabs through trapping has allowed successful Eelgrass restoration in Little Port
Joli Estuary on the Atlantic coast of Nova Scotia (MTRI and Parks Canada 2014),
although the Green Crab population threshold for vegetation survival is as yet unknown
(Kanary et al. 2014). Management interventions to control Green Crabs are
similarly being considered in Maine (MDMR 2013). Historical evidence suggests
that the abundance of Green Crabs in New England is regulated at least in part
by water temperature, with population declines following periods of colder than
average temperatures (Berrill 1982, Welch 1968). Although it is unknown whether
Green Crab populations in coastal Maine will decline naturally or will require management
control, results of my exclosure experiment suggest that natural recovery
or restoration of Eelgrass in upper Casco Bay may be impossible until Green Crab
population levels have decreased.
Acknowledgments
Seth Barker’s long contribution to mapping Eelgrass in Maine waters was critical in
recognizing and quantifying the recent loss of vegetation in upper Casco Bay. It was through
the assistance of many people concerned about Eelgrass that I was able to initiate a field experiment
only 6 weeks after the extensive decline was discovered. I owe tremendous debts
of gratitude to Dan Devereaux for helping to acquire the federal, state, and local permits and
approvals needed to establish exclosures, collect Eelgrass, and trap Green Crabs in Casco
Bay; to George Lapointe for constructing the exclosure frames and helping me harvest the
experiment; and to Dan Devereaux, Chris Green, John Lichter, and Andre Lopez for helping
to install the exclosures. Dan Devereaux and Paul Plummer also performed yeoman service
in dismantling and removing the exclosures for me during the federal government shutdown.
I thank several colleagues for sharing information generously and promptly that allowed me
to hit the field running: Darcie Couture on effective fencing design to exclude Green Crabs;
Seth Barker and John Sowles on the locations of persistent Eelgrass donor beds closest to
upper Casco Bay; Holly Bayley on use of rebar as anchors for Eelgrass transplanting; Fred
Short on minimizing potential effects of Eelgrass wasting disease during transplanting; and
Denis Nault on trapping Green Crabs in and around experimental exclosures. Emily Smaha,
Ryan Jaret, Steve Custer, and the L.L. Bean Paddling Center were instrumental in allowing
me regular access to the study site from the Paddling Center shoreline. Bait for the crab
traps was donated generously by Free Range Fish and Lobster market in Portland, ME. This
manuscript was improved greatly by the comments of Tom Trott, Jane Disney, Robin White,
and 4 anonymous reviewers. Funding was provided by the US Geological Survey Patuxent
Wildlife Research Center. Use of trade, product, or firm names does not imply endorsement
by the US Government.
Literature Cited
Barker, S. 2013. Eelgrass distribution in Casco Bay. Final project and data report. Maine
Department of Environmental Protection, Augusta, ME. 15 pp.
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
495
Beal, B.F. 2014. Final report: Green Crab, Carcinus maenas, trapping studies in the Harraseeket
River and manipulative field trials to determine effects of Green Crabs on the fate
and growth of wild and cultured individuals of Soft-shell Clams, Mya arenaria (May
to November 2013). Downeast Institute for Applied Marine Research and Education,
Beals, ME. 76 pp. Available online at http://www.downeastinstitute.org/assets/files/
manuals/1_24-Final-Report---Freeport-Shellfish-Restoration-Project---B.-Beal.pdf.
Accessed 1 March 2015.
Bergmann, N., G. Winters, G. Rauch, C. Eizaguirre, J. Gu, P. Nelle, B. Fricke, and T.B.H.
Reusch. 2010. Population-specificity of heat stress gene induction in northern and southern
Eelgrass Zostera marina populations under simulated global warming. Molecular
Ecology 19:2870–2883.
Berrill, M. 1982. The life cycle of the Green Crab Carcinus maenas at the northern end of
its range. Journal of Crustacean Biology 2:31–39.
Bintz, J.C., S.W. Nixon, B.A. Buckley, and S.L. Granger. 2003. Impacts of temperature and
nutrients on coastal lagoon plant communities. Estuaries 26:765–776.
Blakeslee, A.M.H., C.H. McKenzie, J.A. Darling, J.E. Byers, J.M. Pringle, and J. Roman.
2010. A hitchhiker’s guide to the Maritimes: Anthropogenic transport facilitates longdistance
dispersal of an invasive marine crab to Newfoundland. Diversity and Distributions
16:879–891.
Borum, J. 1996. Shallow waters and land–sea boundaries. Pp. 179–203, In B.B. Jørgensen
and K. Richardson (Eds.). Eutrophication in Coastal Marine Ecosystems. American
Geophysical Union, Washington, DC. 280 pp.
Burdick, D.M., F.T. Short, and J. Wolf. 1993. An index to assess and monitor the progression
of wasting disease in Eelgrass, Zostera marina. Marine Ecology Progress Series
94:83–90.
Burkholder, J.M., D.A. Tomasko, and B.W. Touchette. 2007. Seagrasses and eutrophication.
Journal of Experimental Marine Biology and Ecology 350:46–72.
Carruthers, T.J.B., B.J. Longstaff, W.C. Dennison, E.G. Abal, and K. Aioi. 2001. Measurement
of light penetration in relation to seagrass. Pp. 369–392, In F.T. Short and R.G.
Coles (Eds.). Global Seagrass Research Methods. Elsevier Science B.V., Amsterdam,
The Netherlands. 473 pp.
Casco Bay Estuary Partnership (CBEP). 2005. State of the bay report. Casco Bay Estuary
Partnership, Portland, ME. 50 pp.
CBEP. 2010. State of the bay report. Casco Bay Estuary Partnership, Portland, ME. 81 pp.
Cohen, A.N., J.T. Carlton, and M.C. Fountain. 1995. Introduction, dispersal, and potential
impacts of the Green Crab Carcinus maenas in San Francisco Bay, California. Marine
Biology 122:225–237.
Darling, J.A., M.J. Bagley, J. Roman, C.K. Tepolt, and J.B. Geller. 2008. Genetic patterns
across multiple introductions of the globally invasive crab genus Carcinus. Molecular
Ecology 17:4992–5007.
Davis, R.C., and F.T. Short. 1997. Restoring Eelgrass, Zostera marina L., habitat using a
new transplanting technique: The horizontal rhizome method. Aquatic Botany 59:1–15.
Davis, R.C., F.T. Short, and D.M. Burdick. 1998. Quantifying the effects of Green Crab
damage to Eelgrass transplants. Restoration Ecology 6:297–302.
Dennison, W.C. 1987. Effects of light on seagrass photosynthesis, growth, and depth distribution.
Aquatic Botany 27:15–26.
Devereaux, D. 2013. Municipal resource management adaptation to changing coastal environments.
Maine Green Crab Summit, 16 December 2013, Orono, ME. Available online
at http://seagrant.umaine.edu/green-crab-summit. Accessed 24 February 2015.
Northeastern Naturalist
496
H.A. Neckles
2015 Vol. 22, No. 3
Disney, J.E., L. Thorburn, and G.W. Kidder III. 2014. Possible causes of Eelgrass (Zostera
marina L.) loss in Frenchman Bay, Maine. The Bulletin, Mount Desert Island Biological
Laboratory 53:26–28.
Duarte, C.M. 1991. Seagrass depth limits. Aquatic Botany 40:363–377.
Duarte, C.M. 2002. The future of seagrass meadows. Environmental Conservation 29:192–
206.
Duarte, C.M., N. Marbá, N. Agawin, J. Cebrián, S. Enríquez, M.D. Fortes, M.E. Gallegos,
M. Merino, B. Olesen, K. Sand-Jensen, J. Uri, and J. Vermaat. 1994. Reconstruction of
seagrass dynamics: Age determinations and associated tools for the seagrass ecologist.
Marine Ecology Progress Series 107:195–209.
Duarte, C.M., I.E. Hendriks, T.S. Moore, Y.S. Olsen, A. Steckbauer, L. Ramajo, J.
Carstensen, J.A. Trotter, and M. McCulloch. 2013. Is ocean acidification an open-ocean
syndrome? Understanding anthropogenic impacts on seawater pH. Estuaries and Coasts
36:221–236.
Ehlers, A., B. Worm, and T.B.H. Reusch. 2008. Importance of genetic diversity in Eelgrass
Zostera marina for its resilience to global warming. Marine Ecology Progress Series
355:1–7.
Erftemeijer, P.L.A., and E.W. Koch. 2001. Sediment geology method for seagrass habitat.
Pp. 345–367, In F.T. Short and R.G. Coles (Eds.). Global Seagrass Research Methods.
Elsevier Science B.V., Amsterdam, The Netherlands. 473 pp.
Erwin, R.M. 1996. Dependence of waterbirds and shorebirds on shallow-water habitats in
the mid-Atlantic coastal region: An ecological profile and management recommendations.
Estuaries 19:213–219.
Evans, A.S., K.L. Webb, and P.A. Penhale. 1986. Photosynthetic temperature acclimation in
two coexisting seagrasses, Zostera marina L. and Ruppia maritima L. Aquatic Botany
24:185–197.
Gaeckle, J.L., and F.T. Short. 2002. A plastochrone method for measuring leaf growth in
Eelgrass, Zostera marina L. Bulletin of Marine Science 71:1237–1246.
Garbary, D.J., A.G. Miller, J. Williams, and N.R. Seymour. 2014. Drastic decline of an
extensive Eelgrass bed in Nova Scotia due to the activity of the invasive Green Crab
(Carcinus maenas). Marine Biology 161:3–15.
Glude, J.B. 1955. The effects of temperature and predators on the abundance of the Soft-
Shell Clam, Mya arenaria, in New England. Transactions of the American Fisheries
Society 84:13–26.
Greiner, J.T., K.J. McGlathery, J. Gunnell, and B.A McKee. 2013. Seagrass restoration
enhances “blue carbon” sequestration in coastal waters. PLOS ONE 8(8): e72469.
doi:10.1371/journal.pone.0072469.
Greve, T.M., J. Borum, and O. Pedersen. 2003. Meristematic oxygen variability in Eelgrass
(Zostera marina). Limnology and Oceanography 48:210–216.
Greve, T.M., D. Krause-Jensen, M.B. Rasmussen, and P.B. Christensen. 2005. Means of
rapid Eelgrass (Zostera marina L.) recolonisation in former dieback areas. Aquatic
Botany 82:143–156.
Grosholz, E.D., and G.M. Ruiz. 1995. Spread and potential impact of the recently introduced
European Green Crab Carcinus maenas in central California. Marine Biology
122:239–247.
Grosholz, E.D., and G.M. Ruiz. 1996. Predicting the impact of introduced marine species:
Lessons from the multiple invasions of the European Green Crab, Carcinus maenas.
Biological Conservation 78:59–66.
Harwell, M.C., and R.J. Orth. 2002a. Seed-bank patterns in Chesapeake Bay Eelgrass (ZosNortheastern
Naturalist Vol. 22, No. 3
H.A. Neckles
2015
497
tera marina L.): A bay-wide perspective. Estuaries 25:1196–1204.
Harwell, M.C., and R.J. Orth. 2002b. Long-distance dispersal potential in a marine macrophyte.
Ecology 83:3319–3330.
Hauxwell, J., J. Cebrian, and I. Valiela. 2006. Light dependence of Zostera marina annual
growth dynamics in estuaries subject to different degrees of eutrophication. Aquatic
Botany 84:17–25.
Hendriks, I.E., Y.S. Olsen, L. Ramajo, L. Basso, A. Steckbauer, T.S. Moore, J. Howard,
and C.M. Duarte. 2014. Photosynthetic activity buffers ocean acidification in seagrass
meadows. Biogeosciences 11:333–346.
Holmer, M., and L. Laursen. 2002. Effect of shading of Zostera marina (Eelgrass) on sulfur
cycling in sediments with contrasting organic matter and sulfide pools. Journal of
Experimental Marine Biology and Ecology 270:25–37.
Integrated Taxonomic Information System (ITIS). 2015. Integrated taxonomic information
system. Available online at http://www.itis.gov. Accessed 5 March 2015.
Kanary, L., J. Musgrave, R.C. Tyson, A. Locke, and F. Lutscher. 2014. Modelling the dynamics
of invasion and control of competing Green Crab genotypes. Theoretical Ecology
7:391–406.
Kelley, J.T., D.F. Belknap, and R.C. Shipp. 1987. Geomorphology and sedimentary framework
of the inner continental shelf of south central Maine. Open-File Report 87-19.
Maine Geological Survey, Augusta, ME. 76 pp.
Klassen, G., and A. Locke. 2007. A biological synopsis of the European Green Crab, Carcinus
maenas. Canadian manuscript report of Fisheries and Aquatic Sciences No. 2818.
Fisheries and Oceans Canada, Gulf Fisheries Centre, Moncton, NB, Canada. 75 pp.
Koch, E.W. 2001. Beyond light: Physical, geological, and geochemical parameters as possible
submersed aquatic-vegetation habitat requirements. Estuaries 24:1–17.
Kutner, M.H., C.J. Nachtsheim, J. Neter, and W. Li. 2004. Applied Linear Statistical Models.
McGraw-Hill/Irwin, New York, NY. 1396 pp.
Larsen, P.F., A.C. Johnson, and L.F. Doggett. 1983. Environmental benchmark studies in
Casco Bay–Portland Harbor, Maine, April 1980. Technical Memorandum NMFS-F/
NEC-19. National Oceanic and Atmospheric Administration, Woods Hole, MA. 173 pp.
Maine Department of Environmental Protection (MDEP). 2013. Eelgrass beds 2013 (digital
map). Available online at http://www.maine.gov/megis/catalog/metadata/eelgrass2013.
html. Accessed 12 November 2014.
Maine Department of Marine Resources (MDMR). 2009. Molluscan shellfish. Maine
molluscan shellfish resource mapping project (digital map). Available online at http://
www.maine.gov/megis/catalog/metadata/molluscan_shellfish.html. Accessed 12 November
2014.
MDMR. 2012. Maine Eelgrass distribution, 2001–2010. Available online at http://www.
maine.gov/megis/catalog/metadata/eelgrass2010.html. Accessed 12 November 2014.
MDMR. 2013. Green Crab overview, December 2013. Available online at http://www.
maine.gov/dmr/greencrabs/intro.htm. Accessed 12 November 2014.
Malyshev, A., and P.A. Quijón. 2011. Disruption of essential habitat by a coastal invader:
New evidence of the effects of Green Crabs on Eelgrass beds. International Council for
the Exploration of the Sea Journal of Marine Science 68:1852–1856.
Marsh, J.A., Jr., W.C. Dennison, and R.S. Alberte. 1986. Effects of temperature on photosynthesis
and respiration in Eelgrass (Zostera marina L.). Journal of Experimental
Marine Biology and Ecology 101:257–267.
Mascaró, O., T. Valdemarsen, M. Holmer, M. Pérez, and J. Romero. 2009. Experimental
Northeastern Naturalist
498
H.A. Neckles
2015 Vol. 22, No. 3
manipulation of sediment organic content and water column aeration reduces Zostera
marina (Eelgrass) growth and survival. Journal of Experimental Marine Biology and
Ecology 373:26–34.
McCarthy, C. 2013. Estuary therapy: Advances in coastal restoration at Kejimkujik National
Park Seaside. Maine Green Crab Summit, 16 December 2013, Orono, ME. Available
online at http://seagrant.umaine.edu/green-crab-summit. Accessed 4 March 2015.
Mcleod, E., G.L. Chmura, S. Bouillon, R. Salm, M. Björk, C.M. Duarte, C.E. Lovelock,
W.H Schlesinger, and B.R. Silliman. 2011. A blueprint for blue carbon: Toward an
improved understanding of the role of vegetated coastal habitats in sequestering CO2.
Frontiers in Ecology and the Environment 9:552–560.
MER Assessment Corporation. 2013. Town of Yarmouth 2013 Clam survey report. MER
Assessment Corporation, Brunswick, ME. 20 pp. Available online at http://www.
yarmouth.me.us/vertical/sites/%7B13958773-A779-4444-B6CF-0925DFE46122%7D/
uploads/Yarmouth_2013_Clam_Survey_Report_100713_Final.pdf. Accessed 24 February
2015.
Mersey Tobeatic Research Institute (MTRI) and Parks Canada. 2014. 2013 annual report
of research and monitoring in the greater Kejimkujik ecosystem. Kempt, NS, Canada.
94 pp.
Moore, K.A., and J.C. Jarvis. 2008. Environmental factors affecting recent summertime
Eelgrass diebacks in the lower Chesapeake Bay: Implications for long-term persistence.
Journal of Coastal Research Special Issue 55:135–147.
Moore, K.A., and F.T. Short. 2006. Zostera: Biology, ecology, and management. Pp.
361–386, In A.W.D. Larkum, R.J. Orth, and C.M. Duarte (Eds.). Seagrasses: Biology,
Ecology and Conservation. Springer, Dordrecht, The Netherlands. 691 pp.
Moore, K.A., R.L. Wetzel, and R.J. Orth. 1997. Seasonal pulses of turbidity and their relations
to Eelgrass (Zostera marina L.) survival in an estuary. Journal of Experimental
Marine Biology and Ecology 215:115–134.
Moore, K.A., E.C. Shields, and D.B. Parrish. 2014. Impacts of varying estuarine temperature
and light conditions on Zostera marina (Eelgrass) and its interactions with Ruppia
maritima (Widgeongrass). Estuaries and Coasts 37 (Suppl 1):S20–S30.
National Oceanic and Atmospheric Administration (NOAA) Center for Operational Oceanographic
Products and Services (CO-OPS). 2013. Water temperature at 8418150, Portland
ME. Available online at http://tidesandcurrents.noaa.gov/physocean.html?id=8418150.
Accessed 15 March 2015.
Neckles, H.A., R.L. Wetzel, and R.J. Orth. 1993. Relative effects of nutrient enrichment and
grazing on epiphyte–macrophyte (Zostera marina L.) dynamics. Oecologia 93:285–295.
Neckles, H.A., F.T. Short, S. Barker, and B.S. Kopp. 2005. Disturbance of Eelgrass Zostera
marina by commercial mussel Mytilus edulis harvesting in Maine: Dragging impacts
and habitat recovery. Marine Ecology Progress Series 285:57–73.
Nejrup, L.B., and M.F. Pedersen. 2008. Effects of salinity and water temperature on the
ecological performance of Zostera marina. Aquatic Botany 88:239–246.
Olesen, B., and K. Sand-Jensen. 1993. Seasonal acclimatization of Eelgrass, Zostera marina,
growth to light. Marine Ecology Progress Series 94:91–99.
Olesen, B., and K. Sand-Jensen. 1994. Patch dynamics of Eelgrass, Zostera marina. Marine
Ecology Progress Series 106:147–156.
Orth, R.J., and K.A. Moore. 1983. Chesapeake Bay: An unprecedented decline in submerged
aquatic vegetation. Science 222:51–53.
Northeastern Naturalist Vol. 22, No. 3
H.A. Neckles
2015
499
Orth, R.J., T.J.B. Carruthers, W.C. Dennison, C.M. Duarte, J.W. Fourqurean, K.L. Heck Jr.,
A.R. Hughes, G.A. Kendrick, W.J. Kenworthy, S. Olyarnik, F.T. Short, and S.L. Williams.
2006a. A global crisis for seagrass ecosystems. Bioscience 56:987–996.
Orth, R.J., M.L. Luckenbach, S.R. Marion, K.A. Moore, and D.J. Wilcox. 2006b. Seagrass
recovery in the Delmarva coastal bays, USA. Aquatic Botany 84:26–36.
Pringle, J.M, A.M. Blakeslee, J.E. Byers, and J. Roman. 2011. Asymmetric dispersal allows
an upstream region to control population structure throughout a species range. Proceedings
of the National Academy of Sciences 108:15,288–15,293.
Reusch, T.B.H., A. Ehlers, A. Hämmerli, and B. Worm. 2005. Ecosystem recovery after climatic
extremes enhanced by genotypic diversity. Proceedings of the National Academy
of Sciences of the United States of America 102:2826–2831.
Roman, J. 2006. Diluting the founder effect: Cryptic invasions expand a marine invader’s
range. Proceedings of the Royal Society B: Biological Sciences 273:2453–2459.
Ropes, J.W. 1968. The feeding habits of the Green Crab, Carcinus maenas (L.). Fishery
Bulletin 67:183–203.
Rossong, M.A., P.A. Quijón, P.V.R. Snelgrove, T.J. Barrett, C.H. McKenzie, and A. Locke.
2012. Regional differences in foraging behavior of invasive Green Crab (Carcinus maenas)
populations in Atlantic Canada. Biological Invasions 14:659–669.
Sand-Jensen, K., and J. Borum. 1991. Interactions among phytoplankton, periphyton, and
macrophytes in temperate freshwaters and estuaries. Aquatic Botany 41:137–175.
Scattergood, L.W. 1952. The distribution of the Green Crab, Carcinides maenas (L.), in the
Northwestern Atlantic. Maine Department of Sea and Shore Fisheries, Fisheries Circular
No. 8:2–10.
Schwab, D.B., and J.D. Allen. 2014. Size-specific maternal effects in response to predator
cues in an intertidal snail. Marine Ecology Progress Series 499:127–141.
Seymour, N.R., A.G. Miller, and D.J. Garbary. 2002. Decline of Canada Geese (Branta
canadensis) and Common Goldeneye (Bucephala clangula) associated with a collapse
of Eelgrass (Zostera marina) in a Nova Scotia estuary. Helgoland Marine Research
56:198-202.
Short, F.T., and C.M. Duarte. 2001. Methods for the measurement of seagrass growth and
production. Pp. 155–182, In F.T. Short and R.G. Coles (Eds.). Global Seagrass Research
Methods. Elsevier Science B.V., Amsterdam, The Netherlands. 473 pp.
Short, F.T., and C.A. Short. 2003. The seagrasses of the western North Atlantic. Pp. 207–
215, In E.P. Green and F.T. Short (Eds.). World Atlas of Seagrasses. Prepared by the
UNEP World Conservation Monitoring Centre. University of California Press, Berkeley,
CA. 298 pp.
Short, F.T., and S. Wyllie-Echeverria. 1996. Natural and human-induced disturbance of
seagrasses. Environmental Conservation 23:17–27.
Short, F.T., R.C. Davis, B.S. Kopp, C.A. Short, and D.M. Burdick. 2002. Site-selection
model for optimal transplantation of Eelgrass Zostera marina in the northeastern US.
Marine Ecology Progress Series 227:253–267.
Torchin, M.E., K.D. Lafferty, and A.M. Kuris. 2001. Release from parasites as natural
enemies: Increased performance of a globally introduced marine crab. Biological Invasions
3:333–345.
Waycott, M., C.M. Duarte, T.J.B. Carruthers, R.J. Orth, W.C. Dennison, S. Olyarnik, A.
Calladine, J.W. Fourqurean, K.L. Heck Jr., A.R. Hughes, G.A. Kendrick, W.J. Kenworthy,
F.T. Short, and S.L. Williams. 2009. Accelerating loss of seagrasses across the globe
Northeastern Naturalist
500
H.A. Neckles
2015 Vol. 22, No. 3
threatens coastal ecoystems. Proceedings of the National Academy of Sciences of the
United States of America 106:12,377–12,381.
Webber, M.M. 2013. Results of the one-day Green Crab trapping survey conducted along
the Maine coast from August 27 to 28, 2013. Maine Department of Marine Resources,
Augusta, ME. 6 pp.
Welch, W.R. 1968. Changes in abundance of the Green Crab, Carcinus maenas (L.), in
relation to recent temperature changes. Fishery Bulletin 67:337–345.
Williams, L.M., C.L. Nivison, W.G. Ambrose Jr., R. Dobbin, and W.L. Locke. 2015.
Loss of adult novel northern lineages of the invasive Green Crab, Carcinus maenus,
along the Northwestern Atlantic Coast. Benthic Ecology Meeting, 4–7 March 2015,
Quebec City, Quebec, CA. Abstract available online at http://www.bemsociety.org/
uploads/4/2/1/5/42158527/abstracts_bem2015.pdf. Accessed 4 March 2015. [Full article
has now been published with the title “Lack of adult novel northern lineages of
invasive green crab Carcinus maenas along much of the northern US Atlantic coast” in
Marine Ecology Progress Series 532:153–159.]
Winters, G., P. Nelle, B. Fricke, G. Rauch, and T.B.H. Reusch. 2011. Effects of a simulated
heat wave on photophysiology and gene expression of high- and low-latitude populations
of Zostera marina. Marine Ecology Progress Series 435:83–95.
