Southeastern Naturalist
629
C.A. Erickson, C.F.E. Roper, and M. Vecchione
22001177 SOUTHEASTERN NATURALIST 1V6o(4l.) :1662,9 N–6o4. 24
Variability of Paralarval-Squid Occurrence in Meter-net
Tows from East of Florida, USA
Carrie A. Erickson1, Clyde F.E. Roper2, and Michael Vecchione3,*
Abstract - We attempted to determine cross-shelf, diel, and seasonal distribution patterns of
paralarval cephalopods off eastern Florida during a 5-year study that employed both open-net
and discrete-depth closing-net sampling. Based on our 303 samples, abundant and common
squid taxa included the squid Doryteuthis spp., which tended to be in coastal and intermediate
waters, and Abralia cf veranyi (Eye-Flash Squid), Illex spp. (shortfin squid), and Ommastrephidae
Type A (which could include Ommastrephes bartramii [Neon Flying Squid]
and Ornithoteuthis antillarum [Atlantic Bird Squid]), mostly in intermediate and Florida
Current waters. Species diversity and abundance were usually greatest in Florida Current
waters versus coastal and intermediate waters. Overall, however, few patterns were obvious
from these samples. Accessory sampling to examine variability indicated that a large
number of samples are required to infer detailed distribution patterns. We also found that the
difference in variation between sampling at a fixed location and sampling within a moving
parcel of water was not consistent.
Introduction
Little is known about the ecology of paralarval cephalopods in some areas, in
spite of the importance of cephalopods in marine ecosystems and fisheries. Knowledge
about the distribution and species abundance of paralarval squids within
different water masses can help provide insight into the influence of factors such as
current systems on squid ecology (Dawe and Beck 1985, Gonzalez et al. 2005, Vidal
et al. 2010) and spawning sites (Bower 1996). Occurrence of paralarval squids
can also provide information on relative abundance of species and may be useful as
an indicator of general ecology (Jorgensen 2007, Vecchione 1987).
The early life-history of cephalopods has often been studied by sampling with
standard zooplankton gear, similar to studies of ichthyoplankton. We sampled
paralarval cephalopods over a 5-y period using a small boat and plankton nets
from the Smithsonian Marine Station (SMS), Fort Pierce, FL. This study was initially
planned as a continuation of earlier opportunistic studies of the systematics
and ecology of paralarval cephalopods (e.g., Vecchione et al. 2001). Our goal was
to determine species composition and relative abundance along a standardized
transect across the continental shelf into the Florida Current/Gulf Stream system
(hereafter, Florida Current), including vertical distribution. However, as sampling
1Florida Institute of Technology, 150 West University Boulevard, Melbourne, FL 32901.
2Department of Invertebrate Zoology, National Museum of Natural History, Washington,
DC 20013-7012. 3National Marine Fisheries Service, National Systematics Laboratory,
National Museum of Natural History, Washington, DC 20013–7012. *Corresponding author
- vecchiom@si.edu.
Manuscript Editor: Barbara E. Curry
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
630
progressed, we noted that high sampling-variability raised questions about whether
each tow was representative of species composition and relative abundance for
a given time and location. Therefore, we conducted 4 additional series of tows
to examine scales of temporal and spatial variability of paralarval occurrence in
these zooplankton tows.
Paralarval octopods collected in this study were reported by Roper et al. (2015).
Adams (1997) reported taxonomic observations and some general distribution
patterns of the squid paralarvae collected in this study. Here, we summarize the
occurrence of paralarval squids east of central Florida, with emphasis on sampling
variability and the need for a lar ge number of samples to infer with confidence oc -
currence patterns for paralarval squids.
Field-Site Description
We conducted all sampling along a transect extending offshore from Fort Pierce
Inlet, FL. This is an area where bottom depth increases rapidly and the Florida
Current is particularly close to shore. Fixed-station locations and designations are
illustrated in Figure 1. We established 13 sampling stations at 3.7-km (2 nautical
miles) intervals eastward from 3.7 km off the coast across the continental shelf to
a maximum distance of 48.1 km offshore. This transect was designed to span 3 water
masses—coastal, intermediate, and Florida Current. The identity of each water
mass was determined by the temperature and salinity data collected concurrently
with sampling (Adams 1997).
Methods
We conducted 12 sampling trips, each a series of daily excursions from SMS,
with a 12-m boat at opportunistic times of year between February 1987 and August
1991 (Table 1). We collected all specimens aboard the R/V Sunburst using 333-μm
mesh plankton nets on 1-m–diameter ring frames, towed with 3-point bridles from
a wire with a hydrodynamic depressor weight. Sampling duration was 15 minutes
and we recorded flow-meter readings at the beginning and end of each tow. An internally
recording conductivity–temperature–depth (CTD) instrument was attached
to the towing wire between the net and the depressor to record temperature, conductivity
(to calculate salinity), and pressure (depth) at 15-sec intervals continuously
throughout the tow. Prior to each 15-min tow, the CTD was placed ~0.5 m below
sea surface for at least 5 min to equilibrate before it was lowered to the desired
sampling depth.
We collected most samples during daytime hours, but collected discrete-depth
samples taken in 1990 during both day and night. Following each tow, we thoroughly
rinsed the net with seawater, retained the contents, and fixed them in a
solution of 4% formaldehyde in buffered seawater for at least 1 week before rinsing
in fresh water, removing and sorting paralarvae, and preserving them in 50%
isopropanol. We calculated the displacement volume of total zooplankton for each
sample as a rough estimate of plankton biomass. At the end of each sampling day,
Southeastern Naturalist
631
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
we downloaded CTD data to a computer at SMS. We recorded sampling-station
latitude and longitude for all stations using Loran during early trips, or GPS when
it became available on the boat.
Figure 1. Transect-sampling stations for cross-shelf distribution patterns and species abundance
of squid paralarvae during the study period (1987–1991). Numbers in inset box are
the station designations based on the distance offshore (in nautical miles [nmi]; 2 nmi = 3.7
km) of Fort Pierce Inlet.
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
632
We employed the following 5 sampling protocols
(1) We conducted standard transect sampling across the continental shelf off of
Fort Pierce Inlet over a 2-day period for each trip (except the first; Table 1) throughout
this 5-y study (1987–1991). Each daily transect was comprised of 9 stations,
located ~3.7 km apart. We collected paralarval samples with a double-oblique,
open-net tow for 15 mins from the surface to ~200 m, or as near bottom as possible
at station depths less than 200 m. Net depth was determined in all protocols based on wire
angle and the amount of wire deployed. To examine daily variability during the 2
days of transect sampling, we sampled the 3.7–33.3-km stations on 1 day and the
48.1–18.5-km stations the other day, providing overlap along the mid-transect area
18.5–33.3-km offshore. We did not undertake transect sampling during February,
May, October, or November of any year.
(2) To determine the vertical distribution patterns, we conducted separate
discrete-depth sampling throughout the 5-y study. During 1 trip-day, we made 3
“quasi-replicate” tows for each of 3 target depths with closing nets. We selected at
random the order in which depths were sampled. The 3 depths were near-surface
(~3-m depth so the net would be below the boat wake), mid-depth (half the depth
of the bottom tow, up to 100 m, depending on the station depth), and near-bottom
(200-m maximum, but variable depending on the bottom depth of a station). The
near-surface net was simply fished open for 15 min. We rolled nets for mid-depth
and near-bottom with the flow meter inside, attached to a messenger-operated,
double-trip mechanism, lowered to a target depth, opened, towed horizontally for
15 min, and then closed.
(3) In 1990, we assessed diel variability with both day and night sampling. At the
37.0-km station, we collected replicate closing-net samples at depths of 10 m, 60 m,
and 120 m during the day and at night, yielding a total of 18 samples: 9 day samples
Table 1. Summary of sampling trips (multi-day sampling events). Protocol 1: Transect sampling; Protocol
2: Daytime discrete-depth sampling; Protocol 3: Nighttime discrete-depth sampling; Protocol
4: Repetitive sampling at a fixed station 37.0 km offshore; Protocol 5: Repetitive sampling while following
a drogue buoy starting at the station 37.0 km offshore. Note that no transect sampling occurred
during February, May, October, or November in any year. Asterisk (*) = not replicated.
Protocol
Trip Date 1 2 3 4 5
1 25 February 1987 x*
2 9–11 June 1987 x
3 27–29 July 1987 x x
4 21–23 September 1987 x x*
5 11–13 January 1988 x
6 11–14 April 1988 x x*
7 30 August–2 September 1988 x
8 5–8 December 1988 x x
9 27 March 1989 x
10 31 July–2 August 1989 x x
11 17–26 July 1990 x x x x x
12 6–15 August 1991 x x x x
Southeastern Naturalist
633
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
(3 for each depth), and 9 night samples (3 for each depth). Unfortunately, we had
to pool the samples by depth due to variation from designed sampling because of
changing weather conditions.
(4) We conducted repetitive sampling on 3 consecutive days at a fixed location
in 1990 and 1991 to determine short-term and daily variability at a mid-transect
station assumed typical of the transect. We planned 15-min, double-oblique, opennet
tows at the single location 37.0 km offshore, yielding a total of 9 samples per
day and a total of 27 samples for the 3 days. In 1991, on the third day, the boat
experienced mechanical issues so we changed the nine 15-min tows to three 30-min
tows; thus, we collected only 21 samples for the oblique series in 1991.
(5) To examine small-scale variability within a discrete parcel of water, we conducted
sampling for a single day in 1990 and in 1991, by following a surface-water
parcel tracked by a drogue buoy for comparison with the 37.0-km fixed geographic
location described above in Protocol #4. We marked a water mass with a windowshade
drogue buoy, beginning at 37.0 km offshore. We made 9 double-oblique
open-net tows at the location of the drogue-buoy as it drifted with the current,
yielding a total of 9 samples for each year.
Results
Overall patterns
Hydrographic observations are presented in Adams (1997). Our sampling extended
from coastal water, through the transitional waters, and into the Florida
Current. In general, the Florida Current tended to occur in the area from 33.3 km
to 48.1 km offshore. Coastal water occurred from 3.7 km to ~14.8 km offshore, but
this area varied due to the continuous changes in the position of the Florida Current
system. Transitional waters consisted of a narrow band between the coastal
waters and the Florida Current waters. Typically, cooler waters are located towards
the coast and the warmer waters are offshore in the Florida Current, but thermal
stratification by depth was almost always evident.
Due to limitations of using a small boat far offshore in variable weather conditions
and at night, and occasional problems with sampling gear, the actual numbers
of samples collected often did not match the planned numbers described above in
Methods. We collected a total of 303 samples.
Of 1450 cephalopods collected, we identified a total of 1303 paralarval squids
belonging to 25 taxa (Table 2). Table 2 also presents the total numbers for taxa collected
from the standard transect series from 1987 to 1991. Although the numbers
of squid paralarvae per tow varied from 0 to 58, many tows caught 0 (Table 3),
especially inshore. When tallied by taxon, numbers were generally 0–3 per tow.
Tows generally filtered ~1000 m3 of water, but this volume varied greatly. Except
for the most abundant taxa, standardizing the catch for such low numbers to relative
abundance as n/1000 m3 only added variability.
In the strandard transect sampling, we collected >100 specimens for 4 taxa, and
3 other taxa were represented by >50 specimens. The inshore squid Doryteuthis
spp. was most abundant in coastal waters from 1989 to 1991, and in intermediate
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
634
waters during 1987 and 1988. We consistently detected Abralia cf. veranyi (Rüppell)
(Eye-Flash Squid) throughout the study area, but it was most abundant in
the intermediate and Florida Current waters during 1987 and 1988 and mostly
in the Florida Current in 1989 and 1991. Ommastrephidae Type A (Ommastrephes
bartramii (Lesueur) [Red Flying Squid], possibly mixed with Ornithoteuthis antillarum
Adam [Atlantic Bird Squid]) was most abundant in the Florida Current for all
5 years, but was also found in the coastal and intermediate waters. We caught Illex
spp. (shortfin squid) primarily during 1988; it was dominant in the Florida Current
waters, but was also found in the intermediate water region.
Transect sampling (Protocols 1, 4, and 5)
Of the transect samples, only 76% contained squids; positive samples were
as low as 50% on 1 trip (Table 4). Negative samples tended to be those collected
Table 2. Number (n) of paralarval squid specimens collected, ranked by n in regular transect samples.
Total includes all protocols, transect refers to collections during standard-transect sampling
(Protocol 1).
Number collected during
Taxon Total number collected (n) transect sampling (n)
Abralia cf. veranyi (Rüppell) 599 226
Illex spp. 250 134
Doryteuthis spp. 160 129
Ommastrephidae Type A 215 111
Pyroteuthis margaritifera (Rüppell) 157 76
Ommastrephidae Type B 203 65
Pterygioteuthis spp. 146 53
Enoploteuthis anapsis Roper 33 10
Selenoteuthis scintillans Voss 21 10
Leachia atlantica (Degner) 13 8
Enoploteuthis leptura (Leach) 11 4
Octopoteuthis sp. 10 5
Abraliopsis sp. A 17 5
Onychoteuthis cf. banksi (Leach) 22 4
Abraliopsis sp. B 15 3
Unidentified Histioteuthidae 5 2
Thysanotethis rhombus Troschel 2 2
Onychoteuthis sp. 2 2
Walvisteuthis jeremiahi Vecchione et al. 5 2
Cranchia scabra Leach 2 2
Ancistrocheirus lesueuri (d’Orbigny) 3 1
Liocranchia sp. 1 1
Unidentified Pyroteuthidae 88 0
Unidentified Ommastrephidae 10 0
Unidentified Enoploteuthidae 9 0
Unidentified Lycoteuthidae 4 0
Unidentified Cranchiidae 3 0
Liguriella sp. 3 0
Brachioteuthis sp. 1 0
Helicocranchia sp. 1 0
Southeastern Naturalist
635
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
at the inshore stations. Only 1 trip had no negative stations; therefore, the minimum
number of squid specimens per station was generally 0. Maximum number
of specimens per station varied from 4 to 58, with no clear seasonal pattern, but
we often collected higher numbers offshore. The maximum number of taxa per
station ranged from 3 to 11, and the range of maximum specimens per taxon was
2–22, with no clear patterns. Other than when numbers were very low, we found
no clear relationship between numbers of specimens and numbers of taxa per
Table 3. Number (n) of samples collected per year using 5 different Protocols, including (1) oblique
sampling of standard transect, (2 and 3) discrete-depth sampling, including diel comparisons, (4)
repetitive sampling at a fixed location 37.0 km offshore, and (5) sampling in the vicinity of a drogue
buoy launched 37.0 km offshore. N/A = (not applicable); protocol was not conducted that year. Trips
= multi-day sampling events.
% of Total n
1987 1988 1989 1990 1991 Total with squids
Number of trips 4 4 2 1 1 12
Protocol 1: Transect sampling
n 53 61 27 6 9 156
n with squids 46 42 18 4 9 119 76%
Protocols 2 and 3: Discrete-depth sampling
n 15 21 9 18 18 81
n with squids 9 14 4 12 14 53 65%
Protocol 4: Fixed-location (37.0-km station) sampling
n N/A N/A N/A 27 21 48
n with squids N/A N/A N/A 25 21 46 96%
Protocol 5: Drogue-buoy (beginning at the 37.0-km station) sampling
n N/A N/A N/A 9 9 18
n with squids N/A N/A N/A 9 9 18 100%
Grand total
n 68 82 36 60 57 303
n with squids 55 56 22 50 53 236 78%
Table 4. Dates of transect sampling (Protocol 1) trips, with summary of samples and squid paralarval
specimens (spec) and taxa collected. n - number of transect stations (sta).
Sampling trip n n with squids Max spec/sta. Max taxa/sta Max spec/taxon
June 1987 18 15 15 7 6
July 1987 17 16 22 5 20
September 1987 18 15 7 4 2
January 1988 17 14 27 8 11
April 1988 14 7 58 11 22
August–September 1988 16 10 6 3 4
December 1988 14 11 48 8 22
March 1989 9 8 19 10 6
July–August 1989 18 10 12 6 7
July 1990 6 4 4 3 2
August 1991 9 9 35 9 15
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
636
station (i.e., larger numbers of specimens did not necessarily equate to greater
taxonomic richness).
When we detected the high apparent variability in these non-replicated transect
samples, we began accessory sampling (Table 5) to determine how representative a
15-min tow would be for either a fixed location (Protocol 4) or, alternatively, within
a moving parcel of water (Protocol 5). The number of tows required to collect all
of the taxa found in 9 samples at a fixed location on a particular day was 6–9. Returning
to the same station on consecutive days added a little, but not substantially,
to the documented diversity of the station. Sampling in a drifting parcel of water
required fewer tows (3–6) to document the total diversity found in the series. Except
for 1 outlier (6 taxa), the diversity in each full-day series, whether at the fixed
location or drifting, was fairly consistent (10–14 taxa per day). The number of squid
specimens per tow and specimens per taxon, however, varied greatly among tows
within a day, and both among days in a year and between years.
Short-term variability in inferred abundance of even the most common and
abundant species was also high (Figs. 2, 3). This result was partly caused by variability
in the amount of water filtered by a tow. The coefficient of variability (CV
= ratio of standard deviation to mean) for catch of Eye-Flash Squid was 1.04–1.24
for fixed stations and 0.87 in July 1990. In August 1991 these coefficients were
lower—0.5–0.57 for fixed stations and 0.80 in the drogue series.
When we pooled standard transect catches of abundant taxa for all years, we
detected seasonal patterns, but none were very clear. Figure 4 shows the relative
seasonal abundance of the 4 most common and abundant paralarval squid taxa.
Doryteuthis spp. were most abundant in the summer months; however, we also collected
specimens in the cooler months. Eye-Flash Squid was present year-round and
Table 5. Sets of 9 consecutive samples. Tows req = the number of consecutive 15-min tows that were
required to collect all taxa found in the entire 9-tow series for that day. Added = the number of taxa
added by sampling more than 1 day in the 3-day series for a fixed location. *On 9 August 1991, we
were unable to follow the standard protocol of nine 15-min tows and collected only 3 samples from
longer tows. N/A = not applicable.
Date Number of taxa Tows req Specimens/tow Taxa/tow Added
1990 Fixed location (37.0-km station, Station 20 on Fig. 1)
23 July 1990 14 9 1–8 1–5 N/A
24 July 1990 6 6 0–5 0–3 0
25 July 1990 10 9 0–7 0–6 1
1990 Drogue-buoy series (beginning at the 37.0-km station)
20 July 1990 12 3 3–10 2–7 N/A
1991 Fixed location (37.0-km station)
7 August 1991 11 8 9–28 3–8 N/A
8 August 1991 11 7 6–29 4–8 2
9 August 1991* 10 3* 27–35 6–9 0
1991 Drogue-buoy series (beginning at the 37.0-km station)
12 Aug 1991 12 6 10–57 5–8 N/A
Southeastern Naturalist
637
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
Figure 2. Abundance of paralarval Abralia cf veranyi in consecutive tows (Protocol 4) at the
37.0-km station on 3 consecutive days in 1990 and 1991.
Figure 3. Abundance
of paralarval
Abralia cf veranyi
in consecutive
tows while following
a drogue buoy
(Protocol 5), starting
at the 37.0-km
station in 1990.
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
638
Figure 4. The relative dominance of the 4 most common and abundant paralarval squid taxa
observed during transect sampling (Protocol 1) in pooled samples from different seasons
offshore of Fort Pierce Inlet during the present study. No transect sampling occurred during
February, May, October, or November of any year.
dominant in August. We collected few Eye-Flash Squid in September, but larger
numbers occurred in December and January. Ommastrephidae Type A (Red Flying
Squid and Atlanic Bird Squid) were the most abundant in April, June, and July, but
not very prevalent in the other months. We observed Shortfin Squid primarily in
winter, but they were present throughout the year except during late summer.
Depth distribution (Protocol 2) and diel variability (Protocol 3)
Discrete-depth sampling (Protocol 2) included 4 sets of triplicate samples and 1
set of 5 replicates, plus 1 set of triplicate day/night comparisons (Protocol 3). These
samples included 0–19 squid paralarvae. Occurrence of taxa in individual samples
was quite variable. In general, we collected more specimens and taxa at mid-depth
than near-surface or near-bottom. Pterygioteuthis sp. was consistently abundant in
all mid-depth samples during the diel comparison, both day and night. Otherwise,
variability was so great (Table 6) that we could make no consistent inferences about
vertical distribution or diel migration for any taxon.
Southeastern Naturalist
639
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
Discussion
The overall characteristic of all of the analyses of these data was overwhelming
variability. Based on the accessory sampling, it appears that a full day at each station,
using standard meter nets, would be required to effectively assess the diversity
and abundance of squid paralarvae in the study area. However, our addition of 2
sampling days (Days 2–3 in Protocol 4) did not contribute substantially to inferences
of diversity or abundance. Of course, if the goal is to infer fairly small-scale
spatial patterns, as it was here, spending a day at each station would not only necessitate
greatly increased time at sea, but would also cause spatial patterns to be
confused with potential day-to-day variability over the 13 days (at least) that would
be required. For discrete-depth sampling, triplicate sampling was generally not sufficient
to infer meaningful patterns.
The difference in variation between sampling at a fixed location and sampling
within a moving parcel of water was not consistent between the years. It appeared
that fewer samples may be required with Protocol 5 (drogue buoy) than Protocol
4 (fixed station) to document the full paralarval diversity present on a given day.
The low coefficients of variability (~1 or less) in both the fixed-location and drogue
sampling indicate that the mean abundance inferred from these 9 samples would be
a reasonable estimate at that station and date, at least for the most abundant species.
Although we have only 2 such comparisons, there may be little advantage in the
more difficult sampling plan of trying to stay within a discrete water mass, compared
to focusing on a geographic location; however, this would probably not be
true in an area where there is great temporal variability in the water masses present
at a location (e.g., where river plumes or current eddies likely occur).
Our inability to identify all specimens confidently to species also impaired
the strength of inferences that we could determine from the data. For example,
Table 6. Discrete-depth sampling. Replicates = number of samples per depth; Taxa = number of taxa
collected in the entire series; >3 spec = number of occurrences when any taxon had >3 specimens in a
single sample; taxon = the taxon that had >3 specimens in a sample; where = depth stratum and number
of samples in which taxon with >3 specimens was found; surf = near-surface; mid = mid-depth; bot =
near-bottom; D = daytime samples; N = nighttime samples.
Sampling trip Replicates Taxa >3 species Taxon Where
Feb 1987 1 2 0
Jul 1987 3 5 1 Ommastrephidae type B 1 surf
Sep 1987 1 1 0
Apr 1988 3 6 2 Doryteuthis sp. 1 mid, 1 bot
Sep 1988 1 3 0
Dec 1988 3 10 1 Illex sp. 1 mid
Aug 1989 3 6 0
Jul 1990 (D) 3 4 3 Pterygioteuthis sp. 3 mid
Jul 1990 (N) 3 10 3 Pterygioteuthis sp. 3 mid
14 Aug 1991 1 4 2 A. veranyi 1 surf
Ommastephidae type A 1 surf
15 Aug 1991 5 8 5 A. veranyi 2 mid, 2 bot
Pterygioteuthis margaritifera 1 bot
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
640
the seasonal pattern for the inshore squid Doryteuthis (see Fig. 2) may have been
confused by the presence of both D. pealeii Lesueur (Longfin Inshore Squid) and
D. plei Blainville (Slender Inshore Squid) in the catches. Similarly, Illex spp. may
have comprised as many as 3 species which we could not distinguish morphologically.
Although we think that most of the Abralia that we caught were Eye-Flash
Squid, some A. redfieldi Voss (Redfield's Enope Squid) may have been mixed in,
particularly among the smallest specimens.
We collected >300 samples; thus, we are able to describe some very general
patterns for the squid paralarval fauna of the study area. The highest species abundances
and diversity of paralarval squids consistently occurred in the Florida
Current waters. Roper et al. (2015) reported that the highest total abundance of
the paralarval octopods caught in the same collections was also found offshore
in the Florida Current. The Florida Current is part of the Gulf Stream western
boundary current that flows from the Straits of Florida to beyond the Grand Banks
(Rowell and Trites 1985). The Gulf Stream System generally flows offshore of the
200-m isobath (~37.0–48.1 km off the east coast of Florida, but farther offshore to
the north). Edge filiments and warm-core and cold-core eddies are characteristic
of the Gulf Stream system and the first 2 can transport entrained animals onto the
continental shelf (Vecchione 1981).
The total squid abundance was greatest between the 33.3-km and 40.7-km stations
in 1987, between the 37.0-km and 48.1-km stations in 1988, and between the
44.4-km and 48.1-km stations in 1989, and then moved back to the 33.3-km and
40.7 km stations in 1990 and 1991. These results suggest that squid distribution
across the continental shelf varies as the Florida Current moves on- and offshore.
The discrete-depth series showed that highest total abundance and diversity of
paralarval squids was within the mid-depth zone. Similarly, the highest total abundance
of paralarval squids from the 1990 diel comparison was at the mid-depths
both day and night. Roper et al. (2015) also found that the greatest abundance of
octopod paralarvae in the same collections as examined in this study occurred at
mid-depth.
Limited sampling can contribute valuable information about paralarval biology,
taxonomy, and the developmental morphology of the species collected (e.g., Gonzalez
et al. 2010, Shea 2005). However, sampling for distribution requires coverage
that is more comprehensive. Paralarval surveys have been proposed to be effective
for assessment of cephalopod populations (Jorgensen 2007, Vecchione 1987) and
determination of spawning grounds (Bower 1996, Goto 2002). The present study
was constrained by the capabilities of the available boat and its small winch. The
gear used here, a 1-m diameter ring net with a towing bridle, has been widely used
for zooplankton studies (UNESCO 1974) but is not an optimum method for collecting
cephalopod paralarvae. Many studies of paralarval distribution and abundance
have been byproducts of ichthyoplankton surveys (e.g., Jorgensen 2007). These
studies often use a combination of oblique tows with “bongo” frames (paired nets
rigged so that there is no bridle in front of the net mouths) and surface tows with
some form of neuston nets (e.g., CalCoFI [Koslow and Allen 2011], MARMAP
Southeastern Naturalist
641
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
program [Vecchione et al. 2001]). Surface samples sometimes catch extraordinary
numbers of squid paralarvae (Vecchione 1999), but the surface fauna in our study
area was not sampled by the present methods. Vertical distribution and diel migration
is generally better assessed using a multiple-net opening/closing gear, such as
a MOCNESS (Goldman and McGowan 1991) or rectangular midwater trawl 1 + 8
(Shea and Vecchione 2010) but their use is not possible from a small boat.
The current study has provided information on various scales of temporal and
spatial variability, but few clear patterns were obvious. Our recommendations
to researchers considering similar studies are: (1) use a vessel with sufficient
capability for conducting operations in squalls and at night; (2) choose an effective
sampling gear, with a mouth opening larger than a 1-m diameter and
without a towing bridle in front of the net mouth; and (3) compile a large number
of samples (suggested minimum of several hundred) in order to make confident
inferences about distribution.
Acknowledgments
Carrie Adams Erickson gratefully acknowledges the National Museum of Natural History
(NMNH) for the opportunity to work at the museum and participate in this long-term
project. We heartily acknowledge the continuing support provided by the Smithsonian
Marine Station at Fort Pierce, FL. We most especially thank our colleague, Dr. M.E. Rice
(former Director of the Smithsonian Marine Station) for her strong support of our program.
We warmly acknowledge our research-support staff (H. Reichert, W. Lee, S. Reid,
J. Kaminsky) for their years-long efforts on this research. We heartily thank M.J. Sweeney
(NMNH) for his long participation in the field sampling and his attention to record keeping
as well as his constant good efforts on behalf of the cephalopod program at NMNH. I.H.
Roper and P. Rothman (Smithsonian volunteers) provided invaluable technical support, of
which we are most appreciative. J. Lotze (Director, Eagle Hill Institute, Steuben, ME) was
also essential to the completion of this work. We thank E.M. Jorgensen, who created the
improved version of the map in Figure 1.
Literature Cited
Adams, C.L. 1997. Developmental taxonomy and distribution of paralarval squids from the
Florida Current. M.Sc. Thesis. Florida Institute of Technology, Melbourne, FL. 114 pp.
Bower, J.R. 1996. Estimated paralarval drift and inferred hatching sites for Ommastrephes
bartramii (Cephalopda: Ommastrephidae) near the Hawaiian Archipelago. Fishery Bulletin
(US) 94:398–411.
Dawe, E.G., and P.E. Beck. 1985. Distribution and size of juvenile Short-finned Squid (Illex
illecebrosus) (Mollusca: Cephalopoda) south of Newfoundland during winter. Vie
et Milieu 5:139–147.
Goldman, D.A., and M.F McGowan. 1991. Distribution and abundance of ommastrephid
squid paralarvae off the Florida Keys in August 1989. Bulletin of Marine Science
49:614–622.
Gonzalez, A.F., J. Otero, A. Guerra, R. Prego, F.J. Rocha, and A.W. Dale. 2005. Distribution
of common octopus and common squid paralarvae in a wind-driven upwelling area (Ria
of Vigo, northwestern Spain). Journal of Plankton Research 27:271–277.
Southeastern Naturalist
C.A. Erickson, C.F.E. Roper, and M. Vecchione
2017 Vol. 16, No. 4
642
Gonzalez, A.F., J. Otero, G.J. Pierce, and A. Guerra. 2010. Age, growth, and mortality of
Loligo vulgaris wild paralarvae: Implications for understanding of the life cycle and
longevity. ICES Journal of Marine Science 67:1119–1127.
Goto, T. 2002. Paralarval distribution of the ommastrephid squid Todarodes pacificus during
fall in the southern Sea of Japan and its implication for locating spawning grounds.
Bulletin of Marine Science 71:299–312.
Jorgensen, E.M. 2007. Identification, distribution, and relative abundance of paralarval gonatid
squids (Cephalopoda: Oegopsida: Gonatidae) from the Gulf of Alaska, 2001–2003.
Journal of Molluscan Studies 73:155–165.
Koslow, J.A., and C. Allen. 2011. Influence of the ocean environment on the abundance of
Market Squid, Doryteuthis (Loligo) opalescens, paralarvae in the Southern California
Bight. CalCOFI Report 52:205–213.
Roper, C.F.E., A. Gutierrez, and M. Vecchione. 2015. Paralarval octopods of the Florida
Current. Journal of Natural History 49:1281–1304.
Rowell, T.W., and R.W. Trites. 1985. Distribution of larval and juvenile Illex (Mollusca:
Cephalopoda) in the Blake Plateau Region (Northwest Atlantic). Vie Milieu 35:149–161.
Shea, E.K. 2005. Ontogeny of the fused tentacles in 3 species of ommastrephid squids
(Cephalopoda, Ommastrephidae). Invertebrate Biology 124:25–38.
Shea, E.K., and M. Vecchione. 2010. Ontogenic changes in diel vertical-migration patterns
compared with known allometric changes in 3 mesopelagic squid species suggest an
expanded definition of a paralarva. ICES Journal of Marine Scien ce. 67:1436–1443.
United Nations Educational, Scientific, and Cultural Organization (UNESCO). 1974.
Zooplankton Sampling: Monographs on, oceanographic methodology 2. The UNESCO
Press (2nd Impression), Paris, France. 174 pp.
Vecchione, M. 1981. Aspects of the early life- history of Loligo pealei (Cephalopoda;
Myopsida). Journal of Shellfisheries Research 1:171–-180.
Vecchione, M. 1987. Ecology of juvenile cephalopods. Pp. 61–84, In, P. Boyle, P. (Eed.).,
Cephalopod Life Cycles, volume 2. Academic Press, New York, NY. 441 pp.
Vecchione, M. 1999. Extraordinary abundance of squid paralarvae in surface waters of
the tropical eastern Pacific Ocean during an El Niño event. Fishery Bulletin (US).
97:1025–1030.
Vecchione, M., C.F.E. Roper, M.J. Sweeney, and C.C. Lu. 2001. Distribution, relative abundance,
and developmental morphology of paralarval cephalopods in the western North
Atlantic Ocean. NOAA Technical Report 152, National Marine Fisheries Service. 54 pp.
Vidal, E.A.G., M. Haimovici, and V.C.S. Hackbart. 2010. Distribution of paralarval and
small juvenile cephalopods in relation to primary production in an upwelling area off
southern Brazil. ICES Journal of Marine Science 67:1346–1352.
